Description

The Schneider Electric LC1G800KUEN is a TeSys Giga high-power contactor built for switching large motors and power circuits in demanding industrial applications. It is a 3-pole contactor rated for AC-3 duty up to 800 A at 440 V and supports motor loads up to 450 kW at 400 V. Its wide-band 100–250 V AC/DC electronic coil and high-current design make it suitable for heavy-duty motor control and power switching systems.



Technical Specifications

Condition	New/Never Used Surplus
Brand	Schneider Electric
Category	Industrial Automation
Part Number	LC1G800KUEN
Subcategory	Contactor
Range	TeSys
Product Series	TeSys Giga
Product Type	High power contactor
Poles Description	3P
Pole Contact Composition	3 NO
Auxiliary Contact Composition	1 NO + 1 NC
Rated Operational Voltage	Up to 1000 V AC 50/60 Hz; up to 460 V DC
Rated Operational Current	1050 A AC-1; 800 A AC-3 at <= 440 V
Control Circuit Voltage	100...250 V AC 50/60 Hz; 100...250 V DC
Motor Power	Up to 450 kW at 400 V AC-3
Rated Impulse Withstand Voltage	8 kV
Rated Insulation Voltage	1000 V
Rated Breaking Capacity	5870 A at 440 V
Mechanical Durability	5 Mcycles
Maximum Operating Rate	600 cyc/h AC-3
Mounting Support	Plate
IP Degree of Protection	IP2X front face with shrouds
Ambient Operating Temperature	-25...60 °C
Dimensions	284 mm H x 211 mm W x 266 mm D
Weight	14.2 kg





Information About LC1G800KUEN

The LC1G800KUEN is part of Schneider Electric’s TeSys Giga range, a series of high-power contactors designed for motor control and power switching in large industrial assemblies. It has a 3P (3 NO) main pole arrangement, an embedded 1 NO + 1 NC auxiliary contact block, and front-access control connections that support faster service and replacement in panel installations. The unit uses a 100–250 V AC/DC low-consumption electronic coil with built-in bidirectional peak limiting, and it includes Local Contact Wear Diagnosis for continuous contact-health indication. It is intended for high-load applications where durability, serviceability, and stable operation at temperatures up to 60 °C are required.

Key Features:

• High AC-3 current rating: Rated for 800 A at up to 440 V AC-3 for heavy-duty motor switching.
• Wide-band electronic coil: Uses a 100–250 V AC/DC coil for flexible control voltage compatibility.
• TeSys Giga platform: Built within Schneider Electric’s high-power TeSys Giga contactor range for large industrial systems.
• Integrated auxiliary contacts: Includes 1 NO + 1 NC auxiliary contacts as a built-in standard feature.
• Contact wear monitoring: Local Contact Wear Diagnosis provides health and alarm indication for contact condition.
• Replaceable switching module: Main contacts can be replaced to help extend service life and simplify maintenance.
• High mechanical endurance: Rated for 5 million mechanical operating cycles in demanding duty.
• Broad application coverage: Supports AC and DC utilization categories including AC-1, AC-3, AC-3e, AC-4, and DC-1/DC-3/DC-5.

The LC1G800KUEN delivers the reliability and precision required for high-power motor control and industrial power switching systems.
