Description
The Keyence SR-2000W is a high-performance fixed-mount industrial barcode reader designed for reliable 1D and 2D code reading across an ultra-wide field of view. Equipped with a 2 MP CMOS image sensor, autofocus, high-intensity illumination, and industrial communication protocols, it delivers fast, accurate decoding for manufacturing, logistics, packaging, and traceability applications.
Technical Specifications
| Condition |
New / Surplus Available |
| Brand |
Keyence |
| Part Number |
SR-2000W |
| Category |
Bar Code Equipment |
| Subcategory |
Bar Code Scanner Industrial |
| Product Type |
Fixed-Mount Barcode Reader |
| Series |
SR-2000 |
| Image Sensor |
CMOS |
| Resolution |
2048 × 1536 (2 MP) |
| Focus |
Autofocus |
| Reading Distance |
50–1000 mm |
| Supported Codes |
1D & 2D Barcodes, QR Code, Data Matrix, PDF417, MicroPDF417, GS1, DotCode, UPC, EAN, CODE128, CODE39, and more |
| Illumination |
High-Intensity Red LED with Green Pointer |
| Digital Inputs |
2 |
| Digital Outputs |
3 (Photo MOS Relay) |
| Communication |
Ethernet, RS-232C, USB 2.0 |
| Industrial Protocols |
EtherNet/IP, PROFINET, TCP/IP, MC Protocol, OMRON PLC Link |
| Power Supply |
24 VDC ±10% |
| Current Consumption |
Approx. 1.6 A |
| Protection Rating |
IP65 |
| Operating Temperature |
0°C to +45°C |
| Weight |
0.65 lbs |
Information About SR-2000W
The SR-2000W is part of Keyence's SR-2000 Series of industrial code readers, engineered for high-speed barcode identification in demanding automation environments. Featuring a 2048 × 1536 CMOS image sensor with autofocus and an ultra-wide field of view, it reads a broad range of 1D and 2D symbologies from distances of 50 to 1000 mm. The reader supports EtherNet/IP, PROFINET, TCP/IP, RS-232C, and USB communications for seamless integration into industrial control systems. Its IP65-rated enclosure provides reliable operation in harsh factory environments.
Key Features:
- SR-2000 Series industrial barcode reader
- Ultra-wide field of view for large-area scanning
- 2 MP CMOS image sensor (2048 × 1536)
- Autofocus for flexible reading distances
- Reads 1D and 2D barcodes and DPM codes
- High-intensity red LED illumination with green aiming laser
- Ethernet, RS-232C, and USB communication
- Supports EtherNet/IP, PROFINET, TCP/IP, and OMRON PLC Link
- IP65-rated industrial enclosure
- Designed for manufacturing, logistics, and traceability applications
The SR-2000W delivers high-speed, high-accuracy barcode reading for demanding industrial automation environments.
