Description
The Banner Engineering VE202G1A is a smart industrial vision camera designed for automated inspection, identification, positioning, and quality control applications. Featuring a 2 MP monochrome CMOS image sensor, integrated vision processing, and multiple industrial communication protocols, it delivers reliable performance for demanding manufacturing and machine vision environments.
Technical Specifications
| Condition |
New |
| Brand |
Banner Engineering |
| Part Number |
VE202G1A |
| Category |
Camera & Vision |
| Subcategory |
Video Camera |
| Product Type |
Smart Vision Camera |
| Series |
VE |
| Image Sensor |
CMOS |
| Image Type |
Monochrome |
| Resolution |
2 MP (1600 × 1200 Pixels) |
| Lens Mount |
C-Mount (Lens Required) |
| Supply Voltage |
12–30 VDC |
| Communication |
EtherNet/IP, PROFINET, Modbus/TCP, RS-232, FTP |
| Digital I/O |
6 Optically Isolated I/O |
| Protection Rating |
IP67 |
| Housing Material |
Aluminum |
| Washdown Rated |
Yes |
| Mounting Type |
Chassis Mount |
| Operating Temperature |
0°C to +50°C |
| Software |
Vision Manager Software Included |
| Dimensions (H × W × L) |
88 × 67 × 41 mm |
| Weight |
1.26 lbs |
Information About VE202G1A
The VE202G1A is part of Banner Engineering's VE Series Smart Cameras, combining image acquisition, onboard processing, and industrial networking into a compact IP67-rated device. Equipped with a 1600 × 1200 monochrome CMOS sensor and a C-Mount lens interface, it supports applications including presence detection, defect inspection, part positioning, OCR, and traceability. The camera integrates easily with PLCs and factory automation systems through EtherNet/IP, PROFINET, Modbus/TCP, RS-232, and FTP while utilizing Banner Vision Manager Software for simplified configuration and deployment.
Key Features:
- VE Series smart vision camera
- 2 MP monochrome CMOS image sensor
- 1600 × 1200 image resolution
- Integrated onboard image processing
- C-Mount lens interface (lens required)
- Six optically isolated digital I/O
- EtherNet/IP, PROFINET, Modbus/TCP, RS-232, and FTP communication
- IP67-rated aluminum housing
- Washdown-rated construction
- Compatible with Banner Vision Manager Software
The VE202G1A provides powerful machine vision capabilities for industrial inspection, identification, and quality assurance applications.
