Description
The Automation Direct GS3-4025 DURApulse GS3 Series AC Drive is a 460 VAC variable frequency drive rated for 25 HP industrial motor control applications. It provides precise speed and torque regulation using selectable SVC or V/Hz control modes. This drive is designed for reliable performance in demanding automation environments requiring consistent motor operation.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Automation Direct DURApulse |
| Category |
Industrial Automation |
| Part Number |
GS3-4025 |
| Subcategory |
AC Drives |
| Series |
DURApulse GS3 |
| Drive Type |
AC General Purpose Drive |
| Enclosure Type |
IP20 Enclosed |
| Input Voltage |
460 VAC |
| Input Phase |
3-Phase |
| Horsepower Rating |
25 HP |
| Current Rating |
38 A |
| Control Modes |
SVC (Sensorless Vector Control), V/Hz |
| Frame Size |
D Frame |
| Communication |
RS-485, Modbus |
| Mounting Type |
Panel / Wall Mount |
| Dynamic Braking |
External unit required |
| Short Circuit Current Rating |
5 kA SCCR |
| Weight |
24 lb (approx.) |
Information About GS3-4025
The GS3-4025 is part of the DURApulse GS3 series, engineered for general-purpose AC motor control with robust construction and flexible configuration options. It features a D-frame design suitable for higher horsepower applications and supports panel or wall mounting with an IP20 enclosure. The drive operates on 460 VAC with three-phase input and includes RS-485 communication with Modbus protocol support for integration into automation networks. An external dynamic braking unit is required for applications involving rapid deceleration or stopping.
Key Features:
- High Power Output: Rated for 25 HP (approx. 38A) for demanding motor control applications
- Dual Control Modes: Supports SVC and V/Hz operation for flexible performance tuning
- 460 VAC 3-Phase Input: Designed for industrial power systems and heavy-duty use
- RS-485 Communication: Enables network integration with Modbus protocol support
- D-Frame Construction: Provides stability and durability for higher power applications
- Panel or Wall Mounting: Flexible installation options for control enclosures
- IP20 Enclosure Rating: Suitable for controlled industrial environments
- External Dynamic Braking Support: Requires external unit for controlled deceleration
The GS3-4025 delivers the reliability and precision required for industrial motor speed control and automation systems.
