Description
The Allen-Bradley 1783-CMS6B Stratix 5200 managed switch provides industrial Ethernet connectivity using 4 fast Ethernet copper ports and 2 SFP uplink slots supporting 100/1000 Mbps fiber modules. Designed for star-topology networks in control and automation environments, it enables managed switching functions without routing capability. The 1783-CMS6B is built for DIN rail installation and reliable operation across a wide industrial temperature range.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley (Rockwell Automation) |
| Category |
Industrial Networking |
| Part Number |
1783-CMS6B |
| Subcategory |
Managed Ethernet Switches |
| Product Family |
Stratix 5200 |
| Switch Type |
Managed switch |
| Copper Ports |
4 |
| Copper Port Speed |
10/100 Mbps |
| Fiber Ports (SFP Slots) |
2 |
| SFP Slot Speed |
100/1000 Mbps |
| Combo Ports |
None |
| Routing Capability |
No |
| PoE Support |
No |
| Integrated DLR |
No |
| Network Topology |
Star |
| Network Services |
Standard |
| Environment Rating |
IP30 |
| Mounting |
DIN Rail |
| Operating Temperature |
-40 to 60 °C (-40 to 140 °F) |
| Weight |
3.37 lb |
Information About 1783-CMS6B
The 1783-CMS6B is a managed industrial Ethernet switch in the Allen-Bradley Stratix 5200 family intended for automation cell and machine-level networking. It is designed to integrate with IT-focused tools and Cisco-based network management methods, supporting connectivity to broader enterprise environments while remaining a fixed switching platform. The switch provides four 10/100 copper ports for device-level connectivity and two SFP slots for flexible fiber uplinks, supporting common aggregation or cabinet-to-cabinet links. Its IP30 enclosure and DIN rail mounting format suit control panels and industrial enclosures where consistent environmental tolerance and stable network services are required.
Key Features:
- Managed Switch Architecture: Supports configurable switching features and network monitoring for industrial Ethernet deployments.
- 4x 10/100 Copper Ports: Provides fast Ethernet connectivity for PLCs, HMIs, drives, and other control devices.
- 2x SFP Uplink Slots: Accepts SFP modules with 100 Mbps or 1 Gbps capability for fiber or copper uplinks as required.
- Cisco-Based IT Integration Support: Enables connectivity to IT environments using Cisco technology and tools for management workflows.
- Industrial IP30 Enclosure: Designed for protected industrial control cabinet installations requiring basic ingress protection.
- DIN Rail Mounting Format: Supports quick installation in standard industrial enclosures and automation panels.
- Wide Operating Temperature Range: Rated for operation from -40 to 60°C for industrial environments with temperature variation.
The 1783-CMS6B delivers the reliability and precision required for managed industrial Ethernet switching in automation star networks.
