Description
The 800T-NX970 is a heavy-duty push button switch from Allen-Bradley’s 800T series. Designed for industrial control applications, it features a maintained contact mechanism and durable construction suitable for harsh environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
|
| Part Number |
800T-NX970 |
| Subcatecory |
|
| Action |
Spring Return from Position 4 to Position 3 |
| Conductor Size |
18-14 AWG |
| Contact Configuration |
Customer special |
| Enclosure Rating |
4, 13 |
| Mounting Type |
Hole |
| Size |
30 mm |
| Temperature Rating |
-40 to 55 degrees C |
| Bezel Material |
Metal |
| Contact Rating |
10 A at 600 VAC |
| Operating Cycles |
1000000 Mechanical |
| Standard |
UL,KC,CUL,CSA,MARINE,CE |
| Weight |
0.55 lbs |
Information About 800T-NX970
The 800T-NX970 is a robust push button switch from Allen-Bradley’s 800T series, known for its durability and reliable performance in demanding industrial environments. It is designed for heavy-duty control applications where long-lasting operation and flexibility are essential.
Key Features:
-
Type: Heavy-Duty Push Button Switch
-
Series: 800T
-
Operator Type: Maintained (latching)
-
Contact Configuration: Typically includes 1 normally open (NO) and/or 1 normally closed (NC) contact (exact configuration depends on model specifics)
-
Mounting: Panel mount with standard 30.5 mm mounting hole
-
Material: Rugged metal construction for harsh industrial environments
-
Enclosure Rating: Meets NEMA Type 4/13 (watertight/oil-tight) standards
-
Electrical Ratings: Suitable for a wide range of control voltages and currents
-
Compliance: UL, CSA, and CE certified
-
Applications: Suitable for motor start/stop control, machinery operation, and other industrial control tasks
The 800T-NX970 combines a durable design with easy installation and reliable operation, making it ideal for both new installations and retrofit applications in tough industrial settings.
