Description
The USAGED-09A22K is a 0.85 kW AC servo motor from Yaskawa's G‑Series, designed for industrial motion control applications. It includes an incremental encoder with 8192 pulses per revolution for high-resolution feedback. The motor offers 5.39 Nm of rated torque and supports speeds up to 1500 rpm, making it suitable for direct-drive automation systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Yaskawa |
| Category |
|
| Part Number |
USAGED-09A22K |
| Subcategory |
Servo Motor |
| Rated Output Power |
0.85 kW |
| Rated Torque |
5.39 Nm (48 lb-in)
|
| Peak Torque |
16.3 Nm (144 lb-in)
|
| Rated Speed |
1500 rpm |
| Max Speed |
3000 rpm
|
| Rated Current |
7.6 A |
| Voltage |
200 V AC (nominal)
|
| Encoder Type |
Incremental, 8192 pulses/rev
|
| Moment of Inertia |
12.1×10⁻⁴ kg·m² (21.5×10⁻³ lb·in²)
|
| Insulation Class |
Class F
|
| Cooling Method |
Self-cooled, totally enclosed
|
| Mounting Style |
Flange mount
|
| Drive Method |
Direct drive
|
| Ambient Temp. Range |
0–40 °C
|
| Humidity |
20%–80% (non-condensing)
|
| Enclosure Protection |
Equivalent to IP65
|
| Status |
Discontinued by manufacturer |
| Weight |
25.99 lb (≈11.8 kg)
|
Information About USAGED-09A22K
The USAGED-09A22K is a totally enclosed, self-cooled AC servo motor built to IP65-equivalent standards, offering strong protection in industrial environments. This model delivers continuous torque of 5.39 Nm and peak torque of up to 16.3 Nm, operating at 7.6 A rated current and 200 V input voltage. Its flange-mounted design and permanent magnet excitation enable precise torque delivery and smooth control in direct-drive configurations.
Key Features:
- Rated Power 0.85 kW: Delivers sufficient power for mid-range servo applications.
- Incremental Encoder: 8192 PPR for high-resolution position feedback.
- Rated Torque 5.39 Nm: Provides stable continuous torque for automation systems.
- Peak Torque 16.3 Nm: Supports dynamic motion with high momentary torque.
- 1500 rpm Rated Speed: Standard performance range for servo motion tasks.
- Permanent Magnet Design: Ensures high efficiency and torque density.
- Totally-Enclosed, Self-Cooled: IP65-equivalent enclosure protects against dust and splashing water.
- Insulation Class F: Withstands high thermal loads in demanding environments.
- Mounting Type: Flange-mounted for stable machine integration.
The USAGED-09A22K delivers precise, mid-power servo performance for motion systems requiring incremental feedback and consistent torque.
