Description
The Schneider Electric LXM62DD27D21000 is a high-performance Lexium 62 double servo drive designed for precise multi-axis motion control applications. It delivers efficient power management with a 27 A rating and integrated safety functions for industrial automation systems. This drive is commonly used in manufacturing environments requiring synchronized motor control and high accuracy.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Schneider Electric |
| Category |
Industrial Automation |
| Part Number |
LXM62DD27D21000 |
| Subcategory |
Servo Drives |
| Product Type |
Double Servo Drive |
| Series |
Lexium 62 |
| Rated Current |
27 A |
| Power Output |
4.3 kW |
| Phases |
3 Phase |
| Communication Protocol |
SERCOS III |
| Supply Voltage (Control) |
24 V DC |
| Digital Inputs |
2 |
| Digital Outputs |
2 |
| Touch Probe Inputs |
2 |
| Safety Function |
Safe Torque Off (STO) |
| IP Rating |
IP20 |
| Mounting Type |
Panel Mount |
| Dimensions |
44 x 33 x 11 cm |
| Weight |
4.05 kg |
Information About LXM62DD27D21000
The LXM62DD27D21000 is a double-axis servo drive from Schneider Electric’s Lexium 62 series, developed for compact and modular multi-axis motion systems. It features a robust design with integrated Safe Torque Off functionality, ensuring compliance with safety requirements in industrial applications. The unit supports SERCOS III communication, enabling high-speed data exchange and precise synchronization between multiple drives and controllers. Designed for flexibility, it operates on a 24 VDC control supply and includes digital inputs, outputs, and touch probe interfaces for advanced motion control integration.
Key Features:
- Double-Axis Drive: Controls two servo motors simultaneously for coordinated motion applications
- High Current Capacity: Rated at 27 A to support demanding motor loads
- SERCOS III Communication: Enables real-time, high-speed industrial network integration
- Safe Torque Off (STO): Provides integrated safety functionality for secure operation
- Compact Modular Design: Optimized for space-saving installation in multi-axis systems
- Integrated I/O Interfaces: Includes digital inputs, outputs, and touch probe connections
- Efficient Power Handling: Supports up to 4.3 kW output for high-performance applications
- Easy Commissioning: Designed for simplified installation, setup, and maintenance
The LXM62DD27D21000 delivers the reliability and precision required for advanced multi-axis servo control in industrial automation systems.
