Description
The SICK LUT2-620 is a luminescence sensor designed for detecting fluorescent materials and markings in industrial automation applications. This sensor operates on a 12–30 VDC supply and provides a PNP switching output for reliable signal integration. It is engineered for precise luminescence detection using a defined optical lens configuration.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
SICK |
| Category |
Industrial Sensors |
| Part Number |
LUT2-620 |
| Subcategory |
Luminescence Sensors |
| Sensor Type |
Luminescence Sensor |
| Lens Type |
Lens 211 |
| Sensing Distance |
20 mm |
| Output Type |
PNP |
|
Supply Voltage
|
12–30 VDC |
| Current Consumption |
100 mA |
| Connection Type |
4-pin M12 Connector |
| Operating Principle |
Optical, Luminescence Detection |
| Application |
Fluorescent Mark Detection |
| Mounting Style |
Standard Sensor Mount |
| Weight |
0.35 lbs (approx.) |
Information About LUT2-620
The LUT2-620 is part of SICK’s luminescence sensing product range, developed for identifying UV-reactive and fluorescent features during automated inspection processes. It uses a Lens 211 optical configuration with a 20 mm sensing distance to ensure consistent detection accuracy. The sensor supports PNP output switching and connects via a standardized 4-pin M12 connector for secure installation. Designed for industrial environments, it delivers stable performance with low power consumption and fast optical response.
Key Features:
- Luminescence Detection Technology: Designed to detect fluorescent and UV-reactive materials accurately.
- PNP Switching Output: Provides reliable signal compatibility with PLC and control systems.
- Defined Optical Lens Configuration: Uses Lens 211 for controlled sensing geometry.
- Fixed 20 mm Sensing Distance: Optimized for precise short-range luminescence detection.
- Wide DC Operating Voltage Range: Operates from 12 to 30 VDC for flexible system integration.
- Standard M12 Connector Interface: Uses a 4-pin M12 connector for secure and repeatable wiring.
- Industrial Sensor Design: Built for continuous operation in automation and inspection environments.
The LUT2-620 delivers the reliability and precision required for luminescence-based detection in industrial inspection and verification applications.
