Description
The Banner Engineering LCF12LMP is a megapixel C-mount machine vision lens designed for high-resolution industrial imaging applications. It features a 12 mm focal length and supports sensors up to 2/3 inch, making it suitable for precision inspection tasks. The lens includes locking focus and aperture mechanisms to ensure stable optical performance in demanding environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Banner Engineering |
| Category |
Camera & Vision |
| Part Number |
LCF12LMP |
| Subcategory |
Lens for Camera |
| Lens Type |
C-mount machine vision lens |
| Focal Length |
12 mm |
| Focal Ratio |
F1.4 |
| Maximum Imager Size |
2/3 inch |
| Maximum Resolution |
1600 × 1200 pixels |
| Adjustable Focus |
Yes |
| Locking Focus |
Yes |
| Adjustable Aperture |
Yes |
| Locking Aperture |
Yes |
| Housing Material |
Metal |
| Filter Size |
30.5 mm |
| Mounting Type |
C-mount |
| Weight |
0.18 lbs |
Information About LCF12LMP
The LCF12LMP is a machine vision lens manufactured by Banner Engineering and developed for use with PresencePLUS and iVu vision systems. It is built with a metal housing and uses a standard C-mount interface for compatibility with a wide range of industrial cameras. The lens supports megapixel imaging up to 1600 × 1200 pixels, enabling accurate image capture for inspection and analysis. Locking focus and aperture features help maintain consistent image quality in vibration-prone industrial settings.
Key Features:
-
Megapixel imaging support: Designed for resolutions up to 1600 × 1200 pixels
-
12 mm focal length: Provides a wide-angle field of view for machine vision tasks
-
C-mount interface: Compatible with standard industrial cameras and vision systems
-
Focus lock mechanism: Prevents focus drift during operation
-
Aperture lock mechanism: Ensures consistent exposure settings
-
2/3 inch sensor compatibility: Supports larger industrial image sensors
-
Metal housing: Provides durability in industrial environments
The LCF12LMP delivers the reliability and precision required for industrial machine vision inspection systems.
