Description

The Siemens HF364R is a heavy-duty safety switch rated for 200A, 600V, 3-pole, with a fused, non-automatic configuration. It features a NEMA 3R rainproof enclosure for outdoor use, ensuring reliable disconnect and circuit protection in industrial and commercial applications.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Siemens
Category	Specialized Switches
Part Number	HF364R
Subcategory	Safety Switches
Actuator	Lever
Amperage Rating	200 Amperes
Connection	Mechanical
Contact Configuration	TPST
Environmental Conditions	Wet/Dry Location
Frequency Rating	50/60 Hertz
Material	Steel
Mounting Type	Surface
NEMA Rating	NEMA 3R
Number Of Phases	3-Phase
Number Of Poles	3-Pole
Type	Fusible
Voltage Rating	600 VAC
Width	18.8 Inches
Height	33.9 Inches
Depth	10.2 Inches
Weight	19.05 kgs





Information About HF364R

The Siemens HF364R is a heavy-duty, 200-amp, 600-volt, 3-pole, fused safety switch designed for robust circuit protection and reliable performance in demanding industrial and commercial environments.

Key Features:

• Voltage Rating:

  • 600V AC

  • 250V DC

• Current Rating: 200 amperes

• Horsepower Ratings:

  • Standard:

    • 50 HP at 480V AC

    • 60 HP at 600V AC

  • Maximum (with time-delay fuses):

    • 125 HP at 480V AC

    • 150 HP at 600V AC

• Short-Circuit Current Rating:

  • 10,000 AIC with Class H fuses

  • 200,000 AIC with Class R, J, or T fuses

• Enclosure Type: NEMA 3R, suitable for outdoor use

• Material: 304 stainless steel, offering corrosion resistance

• Operating Mechanism: Quick-make, quick-break action ensuring positive operation

• Visible Blade Design: Double-break switching action with highly visible ON/OFF indication

• Handle: Red handle grip designed for hook stick operation; can be padlocked in the OFF position with up to three padlocks (5/16-inch hasps)

• Certifications:

  • UL Listed under file #E4776

  • Meets UL98 for switches and UL 50 for enclosures

  • Complies with NEMA Standard KS-1 for enclosed switches

  • Seismic qualification compliant with the 2007 California Building Code (CBC) Zone 4

• Additional Features:

  • Defeatable dual cover interlock for added safety

  • Internal shields meeting NEC 2020 230.62 line side barrier requirements

  • Generous wire bending space meeting NEC requirements

• Height: 29.9 inches (759 mm)

• Width: 15.94 inches (405 mm)

• Depth: 12.33 inches (313 mm)

This safety switch is engineered for applications where robust construction, reliable performance, and ease of maintenance are critical. Its NEMA 3R rating ensures suitability for outdoor installations, providing protection against rain and ice formation. The use of 304 stainless steel enhances durability and corrosion resistance, making it ideal for harsh environments.
