The Gigabyte R163-Z35-ACH1 is a high-performance 1U rack server designed for enterprise workloads, hybrid/private cloud infrastructure, and networking. It is built on the AMD SP5 platform, offering massive core density and PCIe Gen5 throughput in a compact form factor.
Specifications
Model Number: R163-Z35-ACH1
Brand: Gigabyte
Alt Part Number(s): R163-Z35-ACH1
Product Type: Barebone Server
Technical Description
Brand: Gigabyte
Model Number: R163-Z35-ACH1
Processor Type: AMD EPYC 9004/ 9005 Series
Processor Core: 128-Core/ 256-Thread
Processor Power: up to ~300 W
Processor Socket: 1 × LGA 6096 (Socket SP5)
Motherboard: 9MZ33DC1UR-000-3
Chipset: System on Chip
Graphics Controller: ASPEED AST2600
Networking: 1 × 1 GbE LAN (Intel I210‑AT), 1 × Management LAN (1 GbE)
RAID Levels: 0, 1, 5, 6, 10
Number of Drive Bays: 12 × 2.5″ hot-swap drive bays
Expansion Slots: 2 × FHHL PCIe Gen5 ×16, 2 × OCP NIC 3.0 PCIe Gen5 ×16
Memory Supported: 3TB
Memory Speed: Up to 6400 MT/s, Up to 4800 MT/s
Memory Technology: DDR5 SDRAM
Memory Slots: 12 × DDR5 RDIMM
Memory Channels: 12-Channels
Cooling: 8 Fans
Power Supply: 1+1 × 1300 W 80 PLUS Titanium redundant
Form Factor: 1U Rackmount
