Overview

Gigabyte G893-SD1-AAX5 is an 8U rackmount GPU server featuring dual 4th or 5th Gen Intel Xeon Scalable processors with up to 350 W TDP and support for 2 TB DDR5 memory across 32 DIMM slots. It includes Nvidia HGX B200 modular GPUs, 8 hot-swap Gen5 NVMe/SATA drives, PCIe Gen5 expansion, and advanced management protocols for high-performance computing and AI workloads.

Specifications

Model Number:  G893-SD1-AAX5

Brand:  Gigabyte

Alt Part Number(s):  G893-SD1-AAX5

Product Type:  GPU Server

Technical Description

Brand:  Gigabyte

Model Number:  G893-SD1-AAX5

Processor Type:  4th,5th Generation Intel Xeon Scalable

4th Gen Intel Xeon:  RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

5th Gen Intel Xeon:  RDIMM: Up to 5600 MT/s (1DPC), 4400 MT/s (2DPC)

Processor Series:  CPU Max

Intel Xeon Max Series:  RDIMM: Up to 4800 MT/s (1DPC), 4400 MT/s (2DPC)

Processor Power:  Up to 350W

Processor Socket:  2 x LGA 4677 Socket E

Chipset Type:  Intel C741

Modular GPU:  Nvidia HGX B200

Motherboard:  MSB3-PE0

Number of Channels:  8-Channel

Storage Hot-swap:  8 x 2.5" Gen5 NVMe/SATA

Controller Type:  PCIe Gen5 x4/SATA 6Gbps

Graphics Controller:  Aspeed AST2600

Memory Supported:  2TB

Memory Technology:  DDR5

Memory Slots:  32 x DIMM

Expansion Slots:  16

Power Supply:  6+6 3000W 80 Plus

Output Voltage:  208 - 230 V AC

Protocols:  Web, SNMP, Telnet

Form Factor: 8U Rackmount/GPU Server

*
