The Gigabyte R113-C10-AC02 (also commonly referenced by its rev. AA02 equivalent) is a cost-optimised 1U rack server designed for entry-level enterprise applications, such as networking and hybrid/private cloud infrastructure.
Specifications
Model Number: R113-C10-AC02
Brand: Gigabyte
Alt Part Number(s): R113-C10-AC02
Product Type: Barebone Server
Technical Description
Brand: Gigabyte
Model Number: R113-C10-AC02
Processor Type: 1 × AM5 AMD EPYC 4005/4004 series
Processor Core: 16 Core/32 Thread
Processor Power: up to 105W
Processor Socket: 1 × AM5 socket
Motherboard: MC13-LE0
Chipset: AMD B650E
Chipset Type: System on Chip
Graphics Controller: ASPEED AST2600
Networking: 2 × 1GbE LAN (Intel I210-AT)
Number of Drive Bays: 2 × 2.5" SATA (hot-swap), 1 × PCIe Gen5 x4
Expansion Slots: PCIe: 1 × FHHL PCIe Gen5 x16
Memory Supported: 128GB
Installed RAM: 64 GB
Memory Technology: DDR5 UDIMM
RAID: 0 / 1 / 10
Memory Speed: Up to 5600 MT/s, Up to 5200 MT/s
Memory Slots: 4 × DIMM
Architecture: Dual-channel
Memory Channels: 2-channel
Power Supply: 400W 80 PLUS Gold PSU
System Cooling: 3 × 40mm high-speed fans
Form Factor: 2U Rackmount
Height: 3.44"
Width: 17.24"
Depth: 32.09"
