The G293-Z23-ACM1 is a high-performance 2U GPU Rackmount Server part of the G-series manufactured by Giga Computing (a GIGABYTE subsidiary). It is specifically engineered for compute-intensive workloads such as AI training, AI inference, and High Performance Computing (HPC).
Specifications
Model Number: G293-Z23-ACM1
Brand: Gigabyte
Alt Part Number(s): G293-Z23-ACM1
Product Type: GPU Server
Technical Description
Brand: Gigabyte
Model Number: G293-Z23-ACM1
Processor Type: AMD EPYC 9005 and 9004 series
Processor Core: 128 Core / 256 threads
Processor Power: Up to 400W
Processor Socket: 1 × LGA 6096 (SP5)
Motherboard: MZB3-G41
Chipset Type: System-on-Chip (SoC)
Graphics Controller: ASPEED AST2600
Networking: 2 × 10GbE RJ-45 (Broadcom BCM57416)
Number of Drive Bays: 4 × 2.5" Gen5 NVMe/SATA/SAS, 4 × 2.5" SATA/SAS, 2 × M.2
Memory Speed: up to 4800–6400 MT/s
Expansion Slots: 2 × LP PCIe Gen5 x16 slots
Memory Supported: 1TB
Memory Size: Up to 96 GB per DIMM
Memory Technology: DDR5 RDIMM
Memory Slots: 12 × DDR5 DIMMs
Number cof Chanels: 12 Chanels
Power Supply: Dual 2200W 80 PLUS Titanium redundant PSU
System Cooling: 4× 80mm high-RPM fans
Form Factor: 2U Rackmount/GPU Server
