| Product Configurations |
High-capacity storage for your demanding applications |
| Storage Controllers |
Dual 1GbE iSCSI controllers with a total of 2GB battery-backed memory which provides up to 72 hours of data protection |
| Network Interfaces |
3x 1GbE Copper per controller |
| Hard Disk Drives |
48x 3.5" 7.2K SATA HDDs |
| Drive Capacities |
500GB, 1TB 7.2K SATA 3.5" HDDs |
| System Capacities |
Up to 48TB |
| Host Protocol |
Any standards-compliant iSCSI initiator |
| Volumes |
Up to 1,024 |
| Snapshots |
512 per volume/up to 10,000 total per group |
| Volume Connections per PS Series Group |
Up to 512/ 2,048 Per Group |
| OS and Hypervisors Supported |
Windows 2000 Server, Windows Server 2003, Windows Server 2008, including Hyper-V, Windows Vista, Windows Server 2008 R2 including Hyper-V, Windows XP, Red Hat Enterprise Linux, SUSE Linux Enterprise, Sun Solaris, IBM AIX, HP-UK, Mac OS X, VMware ESX Server 3/3.5, ESXi 3.5, Citrix XenServer, Novell NetWare, Virtual Iron |
| RAID Supported |
RAID 50 |
| TCP Network Support |
IPv4, IPv6 core support including JITC |
| Expansion Option |
Can be combined with other EqualLogic PS Series online in the same SAN group; PS5500E can only be in a pool with other PS5500E systems |
| Reliability |
Redundant, hot-swappable controllers, power supplies, cooling fans, and disks. Individual disk drive slow power control |
| Enclosure Monitoring System |
Automatic spare configuration and utilization; SMART; Automatic bad block replacement; Auto-Stat Disk Monitoring System (ADMS) to monitor health of data on disk drives |
| Management Interfaces |
Serial Console. Ability to configure a separate management network. SNMP, Telnet, SSH, HTTP, Web (SSL), Host Scripting. Multi-administrator support. |
| Security |
CHAP Authentication; Access control for iSCSI; Access control for management interfaces including RADIUS support |
| Notification Methods |
SNMP traps, e-mail, syslog |
| Physical |
Height: 4U (6.89") Width: 19.01" Depth: 31.90" Weight: 165.00 lbs |
| Power |
Three 440W DC Power Supplies. AC Voltage: 100-240 VAC. Frequency: 47-63 Hz |
| Environmental |
Temperature Range: 5 to 35°C / 41 to 95°F Storage temperature: -20 to 60°C / -22 to 140°F |
