Description
The Eaton CC3225X is a BR series main breaker kit designed to provide primary overcurrent protection and disconnect capability in modular metering systems. Eaton part number CC3225X features a 225 A rating and a three-pole molded case breaker configuration suitable for commercial and residential power distribution. It is commonly used in Eaton modular metering stacks to provide a reliable main breaker for tenant service applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Power Distribution |
| Part Number |
CC3225X |
| Subcategory |
Main Breaker Kit |
| Product Type |
Molded Case Breaker Accessory |
| Circuit Breaker Type |
CC |
| Amperage Rating |
225 A |
| Number of Poles |
Three-pole |
| Voltage Rating |
120/208Y Vac |
| Interrupt Rating |
10 kAIC |
| Compatible Equipment |
1MP, 1MM, 3MM 200 A modular metering stacks |
| Wire Size Range |
#2/0 AWG – 300 kcmil Cu/Al |
| Application |
Main breaker for modular metering equipment |
| Certifications |
UL 489 |
| Warranty |
Limited lifetime residential; 1 year commercial |
| Product Dimensions (L × W × H) |
7.7 × 4.5 × 5.4 in |
| Weight |
2.9 lb |
Information About CC3225X
The CC3225X is a molded case main breaker kit manufactured by Eaton for use with modular metering equipment such as 1MP, 1MM, and 3MM 200 A meter stacks. It serves as a main service disconnect and overcurrent protection device in multi-tenant electrical distribution systems. The breaker is built with a three-pole configuration and supports conductor sizes up to 300 kcmil copper or aluminum. With UL 489 certification and a 10 kAIC interrupt rating, it is designed to meet electrical safety requirements for service entrance equipment.
Key Features:
- 225 Amp Main Breaker Rating: Provides reliable overcurrent protection for service entrance and tenant distribution circuits.
- Modular Meter Stack Compatibility: Designed for use with Eaton 1MP, 1MM, and 3MM 200 A modular metering systems.
- Three-Pole Breaker Design: Supports protection for three-phase electrical distribution systems.
- Main Service Disconnect Capability: Suitable for use as the primary disconnect in metering assemblies.
- High Interrupting Capacity: Rated 10 kAIC to safely interrupt fault currents.
- Flexible Conductor Support: Accepts #2/0 AWG to 300 kcmil copper or aluminum conductors.
- BR Main Breaker Kit Configuration: Integrated breaker assembly designed for quick installation in Eaton meter stacks.
- UL 489 Certified Device: Complies with recognized electrical safety standards.
The CC3225X delivers the reliability and precision required for main service protection in modular electrical metering and tenant distribution systems.
