Description
The Eaton CHSPA60 is a compact spa panel designed to provide ground fault protection and safe power distribution for spa and hot tub installations. Eaton CHSPA60 integrates a factory-installed GFCI breaker to ensure reliable protection against electrical faults. It is ideal for residential outdoor applications requiring dedicated spa circuit protection.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Eaton |
| Category |
Power Distribution |
| Part Number |
CHSPA60 |
| Subcategory |
Spa Panels |
| Product Type |
Spa panel |
| Series |
CH |
| Type |
CH spa panel – Quick Pro |
| Amperage Rating |
60 A |
| Number of Poles |
Two-pole |
| Phase |
Single-phase |
| Enclosure Type |
NEMA 3R |
| Box Size |
5R |
| Number of Wires |
3 |
| Wire Size |
#14–1/0 AWG Cu/Al |
| Included Breaker |
CH260GFI (factory installed) |
| Additional Circuits |
Two extra circuits |
| Product Length/Depth |
9.5 in |
| Product Height |
3.13 in |
| Product Width |
4.5 in |
| Weight |
7 lb |
Information About CHSPA60
The CHSPA60 is a CH series spa panel engineered for quick installation and dependable operation in residential environments. It includes a factory-installed CH260GFI breaker along with additional circuit space for convenience and flexibility. The unit features a NEMA 3R enclosure, allowing for outdoor installation with protection against rain and environmental exposure. Designed for single-phase systems, it supports a wide range of wire sizes and incorporates a ground fault self-test function for enhanced safety and compliance.
Key Features:
- Integrated GFCI Protection: Includes factory-installed CH260GFI breaker for personnel safety.
- 60A Capacity: Supports spa and hot tub electrical loads with reliable performance.
- Quick Pro Design: Simplifies installation with pre-configured components.
- NEMA 3R Enclosure: Provides weather-resistant protection for outdoor use.
- Additional Circuit Space: Allows for expansion with two extra circuits.
- Ground Fault Self-Test: Automatically verifies GFCI functionality for enhanced safety.
- Single-Phase Operation: Designed for residential electrical systems.
- Flexible Wiring: Accepts #14–1/0 AWG copper or aluminum conductors.
The CHSPA60 delivers the reliability and precision required for safe spa and hot tub electrical protection in residential installations.
