Description
The Beckhoff CP6202-0001-0020 is a 15-inch built-in Panel PC with a 1.6 GHz processor, offering storage expandability through HDD, SSD, or CFast cards. Operating on 24 V DC with optional UPS support, it combines display, control, and processing in one compact unit for industrial automation.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Beckhoff |
| Category |
Industrial PCs |
| Part Number |
CP6202-0001-0020 |
| Subcategory |
Panel PCs |
| Device Type |
Built-in Panel PC |
| Display Size |
15-inch display |
| Processor Options |
Intel Celeron, Core i3, Core i5, Core i7 |
| Base CPU |
1.6 GHz |
| Motherboard |
3½-inch motherboard |
| Memory |
Configurable (depending on CPU/motherboard options) |
| Storage Options |
2½-inch HDD/SSD, CompactFlash or CFast card |
| Expansion Slots |
2 × conventional PCI slots |
| Data Protection |
NOVRAM for fail-safe storage |
| Cooling |
Dual ball-bearing fan system |
| Power Supply |
24 V DC with optional integrated UPS |
| Installation |
Built-in, front of control cabinet |
| Housing |
Industrial-grade enclosure |
| Interfaces |
Configurable (per customer-specific setup) |
| Operating Temperature |
0…55°C |
| Protection Rating |
IP20 |
| Certifications |
UL, CE |
| Weight |
11.25 lbs (approx. 5.1 kg) |
Information About CP6202-0001-0020
The CP6202-0001-0020 belongs to Beckhoff’s CP6200 Panel PC series, designed for built-in installation on control cabinet fronts. It features a bright 15-inch display, powered by Intel processors ranging from Celeron to Core i7, paired with a 3½-inch motherboard for scalable computing performance. Storage flexibility is ensured with slots for CFast cards, 2½-inch hard disks, or SSDs, while dual ball-bearing fans provide efficient temperature management for continuous operation. With integrated 24 V DC power supply, NOVRAM data protection, PCI slots for expansion, and UL certification, the CP6202-0001-0020 is engineered for reliability, customization, and long-term industrial use.
Key Features:
-
Integrated Display: Equipped with a 15-inch built-in industrial display for direct operation and monitoring.
-
Processor Scalability: Supports Intel Celeron through Intel Core i7 CPUs, offering flexibility for application requirements.
-
Storage Options: Provides slots for 2½-inch HDD/SSD and CompactFlash or CFast cards, supporting versatile storage configurations.
-
System Reliability: Includes NOVRAM for secure data storage and fail-safe operation in case of power loss.
-
Cooling System: Dual ball-bearing fans ensure reliable thermal management under industrial operating conditions.
-
Power Supply: Runs on 24 V DC with optional integrated UPS for uninterrupted performance.
-
Expansion Capability: Features two conventional PCI slots for additional industrial interfaces or modules.
-
Custom Configuration: Allows flexible customer-specific adaptations to meet application-specific needs.
-
Durable Design: Built-in panel construction for control cabinets with robust front-mount installation.
-
Certified Compliance: UL-certified and compliant with Beckhoff industrial standards for safety and quality.
The CP6202-0001-0020 delivers the reliability and precision required for built-in control, visualization, and processing in industrial automation.
