Description
The Beckhoff AM3021-0C30-0000 is a synchronous servomotor designed for precision motion control in automation systems. With a rated torque of 0.39 Nm, a standstill torque of 0.48 Nm, and a rated speed of 8000 rpm, it delivers efficient and reliable performance with advanced feedback options.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Beckhoff |
| Category |
Motors |
| Part Number |
AM3021-0C30-0000 |
| Subcategory |
Servomotors |
| Series |
AM3000 Servo Motor Series |
| Motor Type |
Synchronous servomotor |
| Cooling |
Convection |
| Nominal Voltage |
480 V AC |
| Rated Power |
0.32 kW |
| Rated Speed |
8000 rpm |
| Rated Torque |
0.39 Nm |
| Standstill Torque |
0.48 Nm |
| Peak Torque |
1.65 Nm |
| Standstill Current |
1.58 A |
| Peak Current |
7.9 A |
| Torque Constant |
0.30 Nm/A |
| Rotor Moment of Inertia |
0.107 kgcm² |
| Motor Feedback |
Resolver, BiSS B, EnDat 2.1 |
| Connection Method |
M23 |
| Ambient Operating Temperature |
+5…+40 °C |
| Installation |
Flange mounting (58 mm, F2 design) |
| Application |
Industrial automation and motion control |
| Weight |
0.62 lbs |
Information About AM3021-0C30-0000
The AM3021-0C30-0000 is part of Beckhoff’s AM3000 servo motor series, known for compact design and high dynamic performance. Designed with a 58 mm flange size (F2), it supports convection cooling and provides reliable torque output for precise control in automation processes. With 480 V AC nominal voltage, it delivers up to 0.32 kW rated power and operates efficiently at speeds of up to 8000 rpm, making it suitable for high-speed applications. Integrated resolver, BiSS B, and EnDat 2.1 feedback interfaces ensure accurate position and speed control, while its lightweight construction allows easy integration into a variety of motion systems.
Key Features:
-
Compact Servomotor Design: Built with a 58 mm flange size for easy integration into compact automation setups.
-
High-Speed Operation: Delivers a rated speed of 8000 rpm, making it suitable for demanding, fast-response applications.
-
Reliable Torque Output: Provides 0.39 Nm rated torque, 0.48 Nm standstill torque, and up to 1.65 Nm peak torque for flexible load handling.
-
Efficient Electrical Performance: Operates on 480 V AC with a 0.32 kW rated power capacity and low standstill current of 1.58 A.
-
Advanced Feedback Options: Supports resolver, BiSS B, and EnDat 2.1 feedback systems for precise motion control and system compatibility.
-
Convection Cooling: Passive cooling ensures quiet and efficient operation without additional cooling equipment.
-
Rugged Construction: Designed for reliable performance within +5…+40 °C operating temperatures in industrial environments.
-
Lightweight Build: Weighing only 0.62 lbs, the motor is easy to install and reduces mechanical load in dynamic systems.
The AM3021-0C30-0000 delivers the reliability and precision required for high-performance motion control in advanced automation systems.
