Description

The Siemens 7KM2112-0BA00-3AA0 is a SENTRON PAC2200 measuring device designed for energy monitoring in industrial and commercial applications. It provides precise measurement of voltage, current, power, and energy consumption in 3-phase systems.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Siemens
Category	Control Devices
Part Number	7KM2112-0BA00-3AA0
Subcatecory	Temperature & Process Controllers
Product Line	SENTRON / 7KM PAC3200
Display Type	LCD
Voltage Rating (L-L)	690 V
Voltage Rating (L-N)	400 V
Current Rating	5 A
Phases Supported	3-phase
Communication Interfaces	Modbus TCP (standard), optional Modbus RTU / PROFINET / PROFIBUS
Measured Parameters	Apparent, Active, Reactive Energy
Accuracy Class	Class 0.5 (IEC 61557-12) / Class 0.5s (IEC 62053-22)
Terminal Type	Screw Terminals
Weight	0,442 kgs
Dimensions	78,00 x 111,00 x 136,00 mm





Information About 7KM2112-0BA00-3AA0

The Siemens 7KM2112-0BA00-3AA0 is part of the SENTRON PAC3200 series—an advanced power monitoring device designed for precise and transparent energy measurement in low-voltage systems. This compact meter is ideal for use in industrial, commercial, and infrastructure applications where real-time monitoring, efficiency tracking, and energy cost control are essential.

Key Features:

Measurement Capabilities:

• Measures voltage, current, power (active, reactive, apparent), and energy consumption

• Suitable for 3-phase systems

• Supports direct or transformer-connected measurement

Electrical Ratings:

• Voltage (Line-to-Line): up to 690 V

• Voltage (Line-to-Neutral): up to 400 V

• Current: up to 5 A

Accuracy and Standards:

• Class 0.5 accuracy per IEC 61557-12

• Class 0.5s accuracy per IEC 62053-22

• High precision for billing and energy optimization

Communication Interfaces:

• Integrated Modbus TCP

• Optional support for Modbus RTU, PROFINET, and PROFIBUS (via communication modules)

• Enables seamless integration with SCADA, BMS, and energy management systems

Display and User Interface:

• Clear LCD display for real-time values and device diagnostics

• Easy navigation using push buttons on the device front

Design and Installation:

• Compact form factor

• DIN rail mountable for easy integration into control panels

• Wide-range AC/DC power supply

• Screw terminals for secure and straightforward wiring

The Siemens 7KM2112-0BA00-3AA0 (PAC3200) offers high-accuracy energy monitoring, flexible communication options, and easy installation, making it a reliable choice for modern energy transparency and system optimization.
