Description
The Copeland ZR25K5E-PFV-800 is a hermetic scroll compressor engineered for air conditioning applications requiring efficient and reliable performance. Operating on 208–230V single-phase power, it delivers a nominal capacity of approximately 24,300 BTU using R-407C or R-22 refrigerants. This compressor is built on Copeland’s proven scroll technology platform and is designed as an OEM-quality replacement for compatible HVAC systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Copeland |
| Category |
HVAC Compressors |
| Part Number |
ZR25K5E-PFV-800 |
| Subcategory |
Scroll Compressors |
| Compressor Type |
Hermetic Scroll |
| Application |
Air Conditioning |
| Cooling Capacity |
24,300–32,800 BTU/hr |
| Refrigerant |
R-407C, R-22 |
| Voltage |
208–230 VAC |
| Phase |
Single Phase |
| Frequency |
50 / 60 Hz |
| Rated Load Amps (RLA) |
13.5–15 A |
| Locked Rotor Amps (LRA) |
68 A |
| Oil Type |
POE |
| Initial Oil Charge |
25 oz |
| Suction Line Size |
3/4 in OD |
| Discharge Line Size |
1/2 in OD |
| Sound Level |
68–73 dBA |
| Height |
15.86 in |
| Length |
9.5 in |
| Width |
9.5 in |
| Weight |
50.1 lb |
| Approvals |
UL Recognized |
Information About ZR25K5E-PFV-800
The ZR25K5E-PFV-800 is part of Copeland’s legacy ZR series scroll compressors developed for low-pressure air conditioning applications. It is designed to support refrigerants such as R-22 and R-407C while maintaining high efficiency and stable operation. The compressor features a compact hermetic design with significantly fewer moving parts than traditional reciprocating compressors, contributing to enhanced reliability and reduced noise. Its construction supports continuous-duty operation in residential and light commercial HVAC environments.
Key Features:
- Copeland Scroll Technology: Provides smooth compression with reduced mechanical complexity and wear.
- Air Conditioning Application: Designed specifically for AC and heat pump systems.
- R-407C and R-22 Compatibility: Supports low-pressure refrigerant applications.
- Single-Phase Power Operation: Operates on 208–230V, 1-phase electrical supply.
- High Energy Efficiency: Achieves EER ratings up to 10.3 for improved system performance.
- Hermetic Compressor Housing: Sealed design enhances durability and minimizes maintenance.
- Low Noise and Vibration: Scroll design delivers quieter operation than reciprocating compressors.
- Liquid Handling Capability: Axial and radial compliance protects against liquid refrigerant damage.
- Compact and Lightweight Design: Simplifies installation and servicing.
The ZR25K5E-PFV-800 delivers the reliability and precision required for scroll compressor operation in modern air conditioning systems.
