Description
The Hanwha Vision XNF-9013RV is a 12MP AI-powered IR fisheye network camera designed for complete 360° situational awareness without blind spots. Featuring a 1/2.3" CMOS sensor and 3008 × 3008 resolution at up to 30 fps, it delivers high-definition panoramic monitoring with on-board dewarping and digital PTZ. The XNF-9013RV integrates AI-based analytics, WiseStream III compression, and built-in IR illumination for reliable surveillance in large indoor and outdoor areas.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Hanwha Vision (Wisenet) |
| Category |
Video Surveillance |
| Part Number |
XNF-9013RV |
| Subcategory |
Fisheye Network Camera |
| Imaging Sensor |
1/2.3" 12MP CMOS |
| Maximum Resolution |
3008 × 3008 |
| Maximum Frame Rate |
30 fps (H.265/H.264) |
| Lens Type |
1.08 mm fixed stereographic |
| Field of View |
187° (H/V/D) |
| Minimum Illumination |
0.39 Lux (Color), 0 Lux (IR On) |
| Wide Dynamic Range |
120 dB (extremeWDR) |
| Video Compression |
H.265 / H.264 / MJPEG |
| IR Range |
Up to 13 m (PoE+), 8 m (PoE) |
| Edge Storage |
Dual Micro SD (Up to 1TB total) |
| Network Interface |
RJ-45 (10/100BASE-T) |
| Ingress Protection |
IP66, IK10, NEMA 4X |
| Operating Temperature |
-40°C to +60°C (-40°F to +140°F) |
| Power Input |
PoE (IEEE 802.3af), PoE+, 12VDC |
| Power Consumption |
Max 23W (PoE+) |
| Dimensions |
Ø160 × 72 mm |
| Weight |
2.58 lb |
Information About XNF-9013RV
The XNF-9013RV is part of the Wisenet AI fisheye series, engineered for wide-area coverage in commercial, retail, transportation, and industrial environments. It utilizes a 1.08 mm stereographic lens providing a 187° field of view in all directions and supports multiple viewing modes including fisheye, single panorama, double panorama, and quad view. Built-in Wise IR II technology delivers adjustable infrared coverage up to 13 m (PoE+) with multi-zone management. The camera incorporates TPM 2.0 hardware security, secure boot, encrypted storage, and firmware verification to meet enterprise cybersecurity requirements.
Key Features:
- 12MP 360° Fisheye Imaging: 3008 × 3008 resolution with 187° panoramic coverage.
- AI-Based Object Detection: Detects person, face, vehicle, and license plate with forensic search support.
- Built-in IR Illumination: Wise IR II with adjustable range up to 13 m (PoE+ mode).
- On-Board Dewarping: Supports fisheye, single/double panorama, quad view, and virtual channels.
- Extreme WDR (120 dB): Enhances image clarity in high-contrast lighting conditions.
- WiseStream III Compression: Optimizes bandwidth and storage efficiency.
- Dual SD Card Slots: Supports up to 1TB (512GB × 2) edge storage.
- Rugged Construction: IP66, IK10, and NEMA 4X rated aluminum housing with hard-coated dome.
- Advanced Cybersecurity: TPM 2.0 (FIPS 140-2 Level 2), secure OS, verified firmware.
The XNF-9013RV delivers the reliability and precision required for enterprise-grade panoramic video surveillance and AI-driven analytics.
