Description
The Cisco WS-C2960CG-8TC-L is a compact Layer 2 managed switch from the 2960-CG Series, featuring 8 Gigabit Ethernet ports and 2 dual-purpose uplink ports. Designed for high-performance access connectivity in space-constrained environments, it offers flexibility and secure LAN base feature sets.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Cisco
|
| Category |
|
| Part Number |
WS-C2960CG-8TC-L |
| Subcatecory |
|
| Total Network Ports |
|
| Network Ports |
8 x 10/100/1000Base-T (Gigabit Ethernet) |
| Uplink Ports |
2 x 1G RJ-45 or SFP Combo Ports |
| Media Type Supported |
Twisted Pair |
| Ethernet Technology |
Gigabit Ethernet |
| Network Technology |
10/100/1000Base-T |
| Forwarding Bandwidth |
10 Gbps |
| RAM |
128 MB |
| Flash Memory |
64 MB |
| Form Factor |
Desktop, Rack-mountable, Wall Mountable |
| Dimensions (H x W x D) |
4.44 x 26.9 x 21.3 cm |
| Weight |
4.38 Kg |
Information About WS-C2960CG-8TC-L
The WS-C2960CG-8TC-L belongs to Cisco’s Compact Catalyst 2960CG series, engineered for secure, Layer 2 access switching with a LAN Base feature set. It is ideal for branch offices, retail spaces, or small workgroups requiring gigabit speeds and intelligent network control. The switch provides 8 x 10/100/1000Base-T Ethernet ports for client access and 2 dual-purpose uplink interfaces, which can be used either as 1G copper or 1G SFP fiber ports. The compact, fanless design allows silent operation and supports desktop, wall, or rack-mountable installation.
Key Features:
- Network Ports: 8 x Gigabit Ethernet ports for full-speed LAN connectivity.
- Uplink Ports: 2 dual-purpose uplinks (1G RJ-45 or 1G SFP) for flexible backbone connections.
- Layer Support: Layer 2 switch functionality with Cisco LAN Base feature set.
- Performance: 10 Gbps forwarding bandwidth ensures low-latency, high-throughput switching.
- Memory: Equipped with 128 MB RAM and 64 MB flash for stable configuration and system operations.
- Media Type Supported: Twisted pair cabling for standard Ethernet environments.
- Manageability: Fully manageable switch with support for Cisco’s enterprise-class configuration tools.
- Form Factor: Compact unit supports desktop, rack, and wall mounting for deployment versatility.
The WS-C2960CG-8TC-L delivers secure Layer 2 connectivity and high-speed switching in a small, silent form factor ideal for tight installation spaces.
