Description
The Westinghouse CA3200 is a molded case circuit breaker designed to provide reliable overcurrent protection in low-voltage electrical distribution systems. Rated at 200 amperes and 240 volts alternating current, it is built for three-phase applications requiring consistent fault interruption. This breaker is commonly used in commercial and industrial panels to safeguard circuits and connected equipment.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Westinghouse |
| Category |
Circuit Breaker |
| Part Number |
CA3200 |
| Subcategory |
Molded Case Circuit Breaker |
| Rated Current |
200 A |
| Voltage Rating |
240 V AC |
| Poles |
3 |
| Phase |
3 Phase |
| Frequency |
50/60 Hz |
| Trip Type |
Thermal-Magnetic |
| Mounting Type |
Panel Mount |
| Status |
Discontinued by Manufacturer |
| Weight |
3.85 lbs |
Information About CA3200
The CA3200 is part of Westinghouse’s molded case circuit breaker lineup, engineered for dependable circuit protection in legacy and retrofit installations. It features a three-pole configuration suitable for three-phase systems operating at 50 or 60 hertz, ensuring compatibility with standard industrial power networks. Designed with thermal-magnetic trip characteristics, it provides both overload and short-circuit protection in a compact housing. Although discontinued by the manufacturer, it remains widely used in existing systems due to its proven reliability and compatibility with older Westinghouse panels.
Key Features:
- High Current Rating: Supports up to 200 amperes for medium-capacity electrical distribution systems.
- Three-Pole Configuration: Designed for three-phase circuit protection in industrial and commercial applications.
- Voltage Compatibility: Rated for 240 volts alternating current for standard low-voltage systems.
- Thermal-Magnetic Trip: Provides combined overload and instantaneous short-circuit protection.
- Molded Case Design: Compact and durable housing ensures long-term operational reliability.
- Frequency Support: Operates at both 50 and 60 hertz for flexible installation environments.
- Legacy System Compatibility: Suitable for maintenance and replacement in existing Westinghouse installations.
The CA3200 delivers the reliability and precision required for protecting electrical distribution systems in industrial and commercial environments.
