[shortdesc]
- 8-60W, Switch, managed, 4 x 10/100/1000 + 4 x 10/100/1000 (PoE), desktop, PoE
[/shortdesc]
[properties]
| Product Name |
Ubiquiti UniFi Switch 8-60W (US-8-60W) |
| Product Description |
Managed 8-port Gigabit switch with four 802.3af PoE ports, suitable for small to medium-sized networks |
| Type |
Managed Gigabit Ethernet Switch |
| Ports |
8 x 10/100/1000 Mbps Ethernet ports (4 with 802.3af PoE) |
| PoE Capability |
Up to 15.4W per PoE port |
| Design |
Compact, fanless, desktop design |
| Management |
Centralized management via UniFi Controller software |
| Supported Voltage Range |
44–57V DC |
[/properties]
[specifications]
| Switching Capacity |
16 Gbps |
| Forwarding Rate |
11.9 Mpps |
| Maximum Power Consumption |
12W (excluding PoE output) |
| Power Method |
External AC/DC adapter: 100-240V AC, 50/60 Hz; 48V DC, 1.25A |
| Dimensions |
148 x 100 x 31 mm (5.8 x 3.9 x 1.2 inches) |
| Weight |
432 g (15.2 oz) |
| Operating Temperature |
-5°C to 45°C (23°F to 113°F) |
| Operating Humidity |
10% to 90% non-condensing |
| PoE Ports |
4 x 802.3af |
| PoE Output |
15.4W per port |
[/specifications]The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port. The US-8 is a PoE Powered 8-port gigabit switch with PoE Passthrough. Perfect for cleanly adding Ethernet ports where needed, with passthrough to keep your PoE device powered.
