- Wireless router, 4-port switch, GigE, 802.11ac Wave 2, 802.11a/b/g/n/ac Wave 2, Dual Band
[/shortdesc]
[properties]
| Properties |
UniFi Dream Machine (UDM) |
| Description |
UniFi Dream Machine (UDM): One Device Combining 802.11ac 4x4 Wave 2 Access Point, 4-Port Switch, Security Gateway, and more.
|
| Product Family |
Ubiquiti UniFi |
| Features |
UniFi Network Controller
DHCP Server
Simultaneous Dual‑Band |
| Networking Interface |
(4) LAN 10/100/1000 RJ45 Ports
(1) WAN 10/100/1000 RJ45 Port |
| Gigabit Switch Ports |
4 |
| Gigabit WAN Port |
1 |
| Dimensions |
Ø 110 x 184.2 mm (Ø 4.33 x 7.25") |
| Maximum Power Consumption |
26W |
| Supported Voltage Range |
100 ‑ 240VAC |
| Power Method |
AC Power Cord |
| Power Supply |
Internal AC/DC Power Adapter (24V, 0.6A, 100 ‑ 240VAC) |
| Power Save |
Supported |
| Beamforming |
Supported |
[/properties][specifications]
| Specifications |
UDM |
| IDS/IPS Throughput |
1 Gbps |
| Processor |
Arm Cortex‑A57 Quad‑Core at 1.7 GHz |
| System Memory |
2 GB DDR RAM |
| On‑Board Flash Storage |
16 GB |
| TX Power |
2.4 GHz: 23 dBm
5 GHz: 30 dBm
|
| Antenna |
(1) Dual‑Band, Quad‑Polarity Antenna |
| Antenna Gain |
2.4 GHz: 3 dBi
5 GHz: 4.5 dBi |
| 2.4 GHz Radio Rate |
300 Mbps |
| 2.4 GHz MIMO |
2x2 (20/40 MHz) |
| 5 GHz Radio Rate |
1733 Mbps |
| 5 GHz MU‑MIMO |
4x4 (20/40/80 MHz) 2x2 (160 MHz) |
| Wi‑Fi Standards |
802.11 a/b/g/n/ac/ac‑wave2 |
| Wireless Security |
WEP, WPA‑PSK, WPA‑Enterprise (WPA/WPA2, TKIP/AES),
802.11w/PMF |
| BSSID |
Up to 8 per Radio |
| Operating Temperature |
‑10 to 45° C (14 to 113° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
[/specifications]
UniFi Dream Machine (UDM) is the easiest way to introduce UniFi to homes and businesses. The UDM includes everything you need for a small-scale wired or Wi-Fi network. It's easy to use and still offers all the benefits of UniFi for homes and businesses.
