• The Ubiquiti UAP-AC-PRO is a ceiling-mounted, dual-band WiFi 5 access point with 6 spatial streams, support for 250+ clients, and coverage up to 1,500 ft². It’s ideal for large offices and enterprise environments

[/shortdesc]

[specifications] [/specifications]

Ubiquiti UAP-AC-PRO UniFi Access Point WiFi 5

The Ubiquiti UAP-AC-PRO is a powerful dual-radio, ceiling or wall-mountable WiFi 5 access point engineered for high-density environments such as business campuses, enterprise offices, and public venues. With 6 spatial streams and support for over 250 concurrent devices, it delivers robust wireless performance across both 2.4 GHz and 5 GHz bands. The access point offers seamless roaming, advanced RF performance, and wireless meshing with features like 802.11r, 802.11k, and 802.11v. PoE-powered with two GbE RJ45 ports, the UAP-AC-PRO is managed via the UniFi Controller and integrates with UniFi Network for centralized control, analytics, and easy deployment.

Key Features:

• High-Density Capacity: Supports 250+ concurrent client devices over dual-band WiFi 5
• Wide Coverage: Provides up to 1,500 ft² (140 m²) of wireless coverage
• 6 Spatial Streams: 3x3 MU-MIMO on both 2.4 GHz and 5 GHz bands for optimal throughput
• Wireless Mesh & Roaming: Includes support for wireless meshing, fast roaming, and band steering for seamless user experience
• Enterprise Authentication: Offers guest portal, PPSK, RADIUS over TLS (RadSec), dynamic VLANs, and captive portal integration
• Dual GbE Ports: Two Gigabit Ethernet ports for flexible uplink or bridging options
• Rugged Build: IP-rated polycarbonate enclosure with ambient operating range from -10°C to 70°C
• Flexible Mounting: Ceiling and wall mounting options with Pro Mount support

Technical Specifications:

• Model: UAP-AC-PRO
• WiFi Standard: WiFi 5 (802.11ac)
• Spatial Streams: 6 total (3x3 MU-MIMO per band)
• Max Data Rate: 5 GHz: 1.3 Gbps (BW80); 2.4 GHz: 450 Mbps (BW40)
• Frequency Bands: 2.4 GHz and 5 GHz
• Antenna Gain: 3 dBi per band
• Max TX Power: 22 dBm on both 2.4 GHz and 5 GHz
• Max. BSSIDs: 8 per radio
• Networking Interface: (2) GbE RJ45 ports
• Power Method: 802.3af/at PoE (PoE adapter included with single unit)
• Max Power Consumption: 9W
• Dimensions: 196.7 x 35 mm (7.7 x 1.4 in)
• Weight: 350 g (450 g with mount)
• Operating Temperature: -10°C to 70°C (14°F to 158°F)
• Enclosure Material: Polycarbonate
• Mounting: Wall or Ceiling (Pro Mount supported)
• Compliance: CE, FCC, IC, Anatel, NDAA-compliant
