Description

The Eaton Bussmann TPH-600 is a 600A, 170V DC Telpower® fuse engineered for high-reliability DC power distribution in telecommunications and industrial systems.

Technical Specifications

Information About TPH-600

The Eaton Bussmann TPH-600 is a high-performance Telpower® fuse rated at 600A and 170V DC, specifically designed for DC power distribution systems in telecommunications and industrial environments. It features a current-limiting design that delivers fast-acting circuit protection and minimizes let-through energy during fault conditions. The fuse utilizes blade-end terminals for bolt-mount installation and is compatible with Eaton's TPHCS series disconnect switches. Its compact form factor and robust construction make it ideal for applications with limited space and critical reliability requirements. Compliant with CE, RoHS, and UR standards, the TPH-600 meets global safety and environmental regulations.

Key Features:

• Current Rating: 600A
• Voltage Rating: 170V DC
• Interrupting Capacity: 100,000A DC
• Fuse Type: Non-indicating, current-limiting
• Terminal Type: Blade-end, bolt-mount
• Installation Compatibility: Designed for use with TPHCS disconnect switches
• Form Factor: Compact size (approx. 38 mm x 89 mm)
• Compliance: CE marked, UL Recognized (UR), RoHS compliant
• Application: DC power systems in telecom and industrial environments

The TPH-600 provides fast, dependable overcurrent protection for sensitive DC circuits, offering industry-standard performance for demanding power infrastructure applications.
