Description
The SP10‑PR001‑V1 is a compact operator interface module from Omron’s SYSMAC mini series (SP10), often used as a handheld programming console for SP-series PLCs. Designed for 240 VAC operation, it integrates seamlessly with SP10 systems, allowing users to set up, monitor, and troubleshoot ladder logic programs.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
|
| Part Number |
SP10-PR001-V1 |
| Subcategory |
Operator Interface |
| Supply Voltage |
240 VAC |
| Reflow Compatibility |
Peak Reflow Compatible (260 °C) |
| Soldering Compatibility |
Leaded Process Compatible |
| Weight |
0.44 lbs |
Information About SP10-PR001-V1
The SP10-PR001-V1 is a compact, handheld programming console from Omron’s SYSMAC mini SP-series, designed for configuring, monitoring, and troubleshooting legacy PLC systems. Built for field flexibility, it connects directly to SP10-series programmable logic controllers and operates on a 240 VAC power supply. Although now discontinued, it remains a practical solution for supporting existing automation setups in industrial environments where SP-series controllers are still in service.
Key Features:
- Legacy System Integration: Specifically designed for use with Omron’s SYSMAC mini SP10, SP16, and SP20 PLCs, providing direct access for programming and diagnostics.
- Handheld Interface: Lightweight and portable, ideal for on-site configuration, program editing, and real-time status monitoring in control cabinets or on the shop floor.
- 240 VAC Operation: Compatible with standard panel power supplies, allowing seamless deployment in industrial environments.
- Reflow-Compatible Design: Built to withstand peak soldering temperatures up to 260 °C, making it suitable for repair or refurbishment processes.
- Leaded Process Compatibility: Fully compatible with traditional soldering standards, extending its serviceability and maintainability.
- Discontinued But Available: While no longer in production by Omron, the SP10-PR001-V1 is still accessible via surplus and refurb vendors for legacy system support.
The SP10-PR001-V1 remains a dependable field tool for maintaining and operating Omron’s SP-series PLCs. Its straightforward operation, durable build, and continued aftermarket availability make it an essential asset for engineers servicing long-running automation systems.
