[shortdesc]SonicWall NSa 5700, SonicOS 7, 1U rack mount, 19 Gbps threat prevention, 24 x 1GbE, 6 x SFP+[/shortdesc]

[properties]

Brand	SonicWall
Model	NSa 5700
SKU	02-SSC-4330
Product Type	Next-generation firewall
Series	Gen 7 NSa Series
Form Factor	1U Rack Mountable
Storage	128GB
Dimensions	43 x 46.5 x 4.5 cm / 16.9 x 18.1 x 1.8 in
Weight	8.1 Kg

[/properties]

[specifications]

Operating System	SonicOS 7
Interfaces	6 x 10G/5G/2.5G/1G SFP+; 2 x 10G/5G/2.5G/1G Cu; 24 x 1GbE Cu; 2 USB 3.0; 1 Console; 1 Mgmt. port
Expansion	Storage Expansion Slot up to 1TB
Firewall Throughput	28 Gbps
Threat Prevention Throughput	19 Gbps
Application Inspection Throughput	18 Gbps
IPS Throughput	20 Gbps
Anti-malware Throughput	18.5 Gbps
TLS/SSL Inspection Throughput	7 Gbps
IPSec VPN Throughput	15 Gbps
Connections Per Second	228,000
Maximum Connections	4,000,000 SPI
Maximum DPI Connections	6,000,000
Site-to-site VPN Tunnels	2,000
Power Supply	350W
Maximum Power Consumption	108.1 W
Operating Temperature	32°-105° F / 0°-40° C
Humidity	5-95% non-condensing
Regulatory Model Number	1RK53-116

[/specifications]

[accesories]

Optional Power Supply

Optional Redundant Power Adapter

[/accesories]

High Speed SonicWall NSa 5700 Firewall Protection

The SonicWall NSa 5700 is a Gen 7 next generation firewall designed for medium to large networks that need multi-gigabit security inspection, dense connectivity, VPN support, and centralized management through SonicOS 7.

Key Benefits and Features

• Delivers up to 19 Gbps threat prevention throughput for demanding network environments.
• Supports SonicOS 7 with policy configuration, zero-touch deployment, and flexible management.
• Includes high port density with 24 x 1GbE Cu ports, 6 x SFP+ ports, and 2 multi-gigabit Cu ports.
• Supports DPI SSL inspection, IPS, anti-malware inspection, application control, and content filtering.
• Provides SD-WAN, dynamic routing, VPN, and high availability features for distributed networks.

Ideal Use Cases

• Internet edge firewall deployment for private enterprise networks.
• Medium and distributed enterprise security architectures.
• Branch office connectivity with secure SD-WAN access.
• VPN and ZTNA environments requiring site-to-site or remote access support.
• Networks requiring high connection capacity and encrypted traffic inspection.

Technical Specifications

• Brand: SonicWall
• SKU: 02-SSC-4330
• Model: NSa 5700
• Operating System: SonicOS 7
• Form Factor: 1U rack mountable
• Interfaces: 24 x 1GbE Cu, 6 x 10G/5G/2.5G/1G SFP+, 2 x 10G/5G/2.5G/1G Cu, 2 USB 3.0, 1 console, 1 management port
• Firewall Inspection Throughput: 28 Gbps
• Threat Prevention Throughput: 19 Gbps
• IPSec VPN Throughput: 15 Gbps
• Maximum Connections: 4,000,000 SPI connections

Upgrade Enterprise Firewall Performance with SonicWall NSa 5700

Choose the SonicWall NSa 5700 for high throughput firewall security, dense enterprise connectivity, and centralized Gen 7 network protection.
