[shortdesc]SonicWall NSa 3700, SonicOS 7, 3.5 Gbps threat prevention, 24x 1GbE ports, 10 SFP+ interfaces[/shortdesc]

[properties]

Brand	SonicWall
Model	NSa 3700
SKU	02-SSC-4326
Product Type	Next-Generation Firewall
Series	Gen 7 NSa Series
Form Factor	1U Rack Mountable
Interface	24x 1GbE Cu, 6x 10G/5G/2.5G/1G SFP+, 4x 5G/2.5G/1G SFP+, 2 USB 3.0, 1 Console, 1 Mgmt. port
Storage	128GB M.2
Dimensions	43 x 32.5 x 4.5 cm / 16.9 x 12.8 x 1.8 in
Weight	4.6 kg / 10.2 lbs

[/properties]

[specifications]

Operating System	SonicOS 7
Expansion	Storage Expansion Slot up to 256GB
Firewall Inspection Throughput	5.5 Gbps
Threat Prevention Throughput	3.5 Gbps
Application Inspection Throughput	3.6 Gbps
IPS Throughput	3.4 Gbps
Anti-Malware Inspection Throughput	2.9 Gbps
TLS/SSL Inspection Throughput	800 Mbps
IPSec VPN Throughput	2.10 Gbps
Connections Per Second	21,000
Maximum Connections	1,500,000 SPI, 750,000 DPI
Site-to-Site VPN Tunnels	4,000
Power Supply	90W
Maximum Power Consumption	21.5 W
Input Voltage	100-240 VAC, 50-60 Hz
Total Heat Dissipation	73.32 BTU
Operating Temperature	32° - 105° F / 0° - 40° C
Storage Temperature	-40° to 158° F / -40° to 70° C
Humidity	0-90% R.H. non-condensing
Regulatory Model Number	1RK52-110
Certifications	ICSA Enterprise Firewall, ICSA Antivirus, IPv6/USGv6

[/specifications]

[accesories]

Optional Power Supply

Optional Redundant Power Supply

[/accesories]

Secure Multi-Gigabit Firewall for Growing Networks

The SonicWall NSa 3700 is a Generation 7 next-generation firewall built for medium and distributed enterprises that need strong inspection performance, flexible connectivity, and centralized security management. It runs SonicOS 7 and supports advanced firewall, VPN, SD-WAN, application control, and deep packet inspection services.

Key Benefits and Features

• Delivers 3.5 Gbps threat prevention throughput for inspected traffic.
• Includes 24x 1GbE ports and multiple multi-gigabit SFP+ interfaces.
• Supports IPS, anti-malware, application control, DPI SSL, and content filtering.
• Runs SonicOS 7 with centralized management and zero-touch deployment support.
• Supports SD-WAN, dynamic routing, and high availability deployments.

Ideal Use Cases

• Internet edge security for medium enterprise networks.
• Distributed branch connectivity with secure SD-WAN.
• Encrypted traffic inspection including TLS 1.3 environments.
• Centralized firewall, switch, and access point management.

Technical Specifications

• Brand: SonicWall
• SKU: 02-SSC-4326
• Model: NSa 3700
• Operating System: SonicOS 7
• Firewall Inspection Throughput: 5.5 Gbps
• Threat Prevention Throughput: 3.5 Gbps
• IPSec VPN Throughput: 2.10 Gbps
• Interfaces: 24x 1GbE Cu, 6x 10G/5G/2.5G/1G SFP+, 4x 5G/2.5G/1G SFP+, 2 USB 3.0, 1 console, 1 management port
• Maximum Connections: 1,500,000 SPI connections
• Form Factor: 1U rack mountable

Deploy SonicWall NSa 3700 for Secure Network Growth

Choose the SonicWall NSa 3700 to strengthen perimeter security, inspect encrypted traffic, and support scalable multi-gigabit network deployments with enterprise-grade firewall capabilities.
