Overview

The S3410-24TS-P is a high-performance Layer 2+ Gigabit Ethernet switch designed for campus network environments. It features 24 ports of 10/100/1000BASE-T RJ45 with support for IEEE 802.3af/at PoE+ (up to 30W per port), complemented by two 10Gb SFP+ uplink ports and two 1G RJ45/SFP combo ports. The switch is powered by a Broadcom BCM56150 chipset and runs the modular PicOS® network operating system, providing robust management and routing capabilities.

Key Features

• 740W PoE+ Power Budget: Supports high-power delivery to connected devices such as Wi-Fi 6 access points, IP cameras, and VoIP phones through IEEE 802.3af/at compliance.
• 10Gb SFP+ Uplinks: Provides two 10Gb SFP+ ports to ensure high-bandwidth connectivity to aggregation layers or core switches, reducing bottlenecks in high-traffic campus networks.
• Multi-Chassis Link Aggregation (MLAG): Enables device-level redundancy by allowing the switch to form logical links across two separate physical switches for high availability.
• PicOS® Operating System: Delivers a modular, software-driven architecture that supports standard L2/L3 protocols, including OSPF and RIP, for enhanced control plane stability.
• Hot-Swappable Redundant Power Supplies: Equipped with a 1+1 redundant power supply design to facilitate continuous operation during power module maintenance or failure.
• Centralized Management via AmpCon: Integrates with AmpCon management software for Zero Touch Provisioning (ZTP), topology auto-discovery, and automated lifecycle management.

Technical Specifications
