Description
The Square D QE2100VH is a 2-pole molded case circuit breaker rated at 100 amps and 240VAC. Designed for reliable overload and short-circuit protection, it features a thermal-magnetic trip mechanism and a high interrupting rating of 22kA at 240V. The QE2100VH provides efficient and dependable performance for both commercial and industrial single-phase power distribution systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Square D |
| Category |
Circuit Breakers |
| Part Number |
QE2100VH |
| Subcategory |
Molded Case Circuit Breakers |
| Series |
QE Series |
| Frame Type |
QE |
| Poles |
2 |
| Phase |
1 |
| Rated Current |
100A |
| Voltage Rating |
240VAC |
| Interrupting Rating |
22kA @ 240V |
| Trip Unit Type |
Thermal-Magnetic |
| Trip Functions |
Long-Time and Instantaneous |
| Mounting Type |
Plug-In |
| Protection Type |
Overload and Short-Circuit |
| Operating Temperature |
40°C |
| Certifications |
UL Listed, CSA Certified |
| Dimensions (W x D) |
1.42 in x 2.24 in (36 mm x 57 mm) |
| Country of Origin |
USA |
| Weight |
1 lb |
Information About QE2100VH
The QE2100VH is part of the Square D QE Series, developed for durable and space-efficient circuit protection. Built with a thermal-magnetic trip unit, this breaker combines long-time and instantaneous trip functions for accurate fault detection and response. Its plug-in design enables quick installation and secure mounting within compatible panelboards. Rated for 40°C ambient temperature and compliant with UL and CSA standards, the QE2100VH ensures dependable operation across a wide range of electrical environments.
Key Features:
- Rated Current: 100A continuous current capacity for reliable load protection.
- Voltage Rating: Operates at 240VAC for residential, commercial, and light industrial use.
- Interrupting Capacity: 22kA at 240V for enhanced short-circuit protection.
- Trip Mechanism: Thermal-magnetic unit offers precise long-time and instantaneous tripping.
- Mounting Style: Plug-in type ensures simple installation and maintenance.
- Poles: 2-pole design for single-phase applications.
- Temperature Rating: Rated for 40°C ambient conditions for stable operation.
- Certifications: UL Listed and CSA Certified for assured quality and compliance.
The QE2100VH delivers the reliability and precision required for efficient and safe circuit protection in demanding electrical systems.
