Overview
PHISON B1201K01960GP021T0200 Pascari BA50P 960GB 2.5 inch SATA Gen3 Non-SED Solid State Drive
Specifications
Model Number:B1201K01960GP021T0200
Brand: PHISON
Alt Part Number(s):B1201K01960GP021T0200
Product Type: Solid State Drive
Technical Description
Brand: PHISON
Model:B1201K01960GP021T0200
Capacity: 960GB
Form Factor: 2.5" SSD
SATA Interface: SATA Gen3
Compliance: Serial ATA Revision 3.2
Performance
Sequential Read: up to 530 MB/s
Sequential Write: up to 500 MB/s
Random Read: up to 98K IOPS
Random Write: up to 30K IOPS
Power Consumption
128K Active Read (Avg. RMS): 2.1W
128K Write (Avg. RMS): 2.7W
4KB Active Read (Avg. RMS): 2.2W
4KB Active Write (Avg. RMS): 3.3W
4KB 70/30 Random READ/WRITE (Average RMS, W): 3.0W
Idle Power: 1.3W
Endurance/Reliability
MTBF: 2.0 million hours
UBER: < 1 sector per 10^17 bits read
DWPD: 1
TBW: 1752TB
Environmental Specifications
Temperature Range:
Operating: 0°C ~ 70°C
Non-operating: -40°C ~ 85°C
Shock:
Operating: 1000G, 0.5ms
Non-operating: 1500G, 0.5ms
Vibration:
Operating: 3.08Grms (7 - 800Hz)
Non-operating: 20G (20 - 2000Hz)
Drop: 80cm height
Bending: 50N force
Certifications and Declarations: CE, FCC, BSMI, VCCI, UKCA, RCM, ICES, KCC, CB, UL
Compliant: RoHS compliant
Feature Support
Hardware Based Power Loss Data Protection
Thermal throttling
End-to-End Data Path Protection
TCG Opal 2.0
*
