Description
The Omron STC-HD213DV is a high-definition industrial camera designed for precision imaging and inspection applications. It features a 2.0 MP CMOS sensor with 1920 × 1080 resolution and supports up to 60 fps for real-time image capture. This camera is used in automation systems requiring accurate visual monitoring and analysis.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Business & Industrial |
| Part Number |
STC-HD213DV |
| Subcategory |
Industrial Cameras |
| Series |
HD213 |
| Camera Type |
Color |
| Resolution |
1920 × 1080 |
| Megapixels |
2.0 MP |
| Frame Rate |
60 fps |
| Sensor Type |
CMOS (1/2.8") |
| Pixel Size |
2.8 µm |
| Shutter Type |
Global |
| Interface |
DVI (HDMI compatible) |
| Lens Mount |
C-Mount |
| Supply Voltage |
9–15 VDC |
| Operating Temperature |
0°C to 48°C |
| Dimensions |
40 × 40 × 48.9 mm |
| Weight |
129 g |
Information About STC-HD213DV
The STC-HD213DV is part of Omron’s industrial imaging solutions (Sentech series), developed for machine vision and inspection tasks. It utilizes a 1/2.8" CMOS sensor with global shutter capability to ensure consistent image capture in dynamic environments. The camera supports DVI output over HDMI, allowing direct connection to monitors without the need for a PC. Its compact cased design with C-mount compatibility enables integration with a wide range of industrial lenses and vision systems.
Key Features:
- 2.0 MP resolution: Provides Full HD 1920 × 1080 image quality for detailed inspection.
- High frame rate: Supports up to 60 fps for real-time imaging applications.
- CMOS image sensor: Ensures efficient image capture with stable performance.
- DVI/HDMI output: Allows direct connection to display devices without additional hardware.
- Global shutter operation: Reduces motion distortion in high-speed environments.
- C-mount lens compatibility: Supports a wide range of industrial lenses.
- Compact industrial design: Enables installation in space-constrained systems.
- Wide operating voltage range: Operates from 9 to 15 VDC for flexible integration.
The STC-HD213DV delivers the reliability and precision required for industrial imaging and machine vision applications.
