Description
The Omron NX-RS1201 is a load cell input module designed for high-precision measurement of force and weight signals in industrial automation systems. It provides a single high-resolution analog input optimized for load cell applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Industrial Automation and Controls |
| Part Number |
NX-RS1201 |
| Subcategory |
Load Cell Input Modules |
| Series |
NX |
| Module Type |
Load Cell Input Module |
| Number of Inputs |
1 (Analog) |
| Input Type |
Load Cell (Differential) |
| Resolution |
24 Bit |
| Conversion Time |
0.125 ms/unit |
| Signal Processing |
Free running, Synchronous |
| I/O System |
NX I/O Bus |
| Connection Type |
Push-in |
| Mounting Type |
DIN Rail |
| Protection Rating |
IP20 |
| Operating Temperature |
0°C to 55°C |
| Dimensions |
100 × 12 × 80 mm |
| Weight |
70 g |
Information About NX-RS1201
The NX-RS1201 is part of Omron’s NX series I/O modules, intended for use within Sysmac automation platforms. It connects via the NX I/O bus and is specifically designed to process signals from load cells with high accuracy. The module features a 24-bit resolution and differential input circuit, ensuring precise measurement and noise resistance. Its compact design and push-in terminal connection make it suitable for modern control panels and distributed I/O systems.
Key Features:
- Load cell input module: Designed for force and weight measurement applications.
- High resolution: 24-bit analog input for precise signal processing.
- Fast conversion time: 0.125 ms per unit for real-time measurement.
- Differential input circuit: Improves noise immunity and measurement stability.
- NX I/O bus compatibility: Integrates with Sysmac automation systems.
- Compact design: 12 mm width for space-saving installations.
- Push-in terminal connection: Enables quick and secure wiring.
- Flexible signal processing: Supports free running and synchronous modes.
The NX-RS1201 delivers accurate and reliable load cell signal acquisition for industrial measurement and control systems.
