Description
The Omron NS5-MQ11-V2 is a programmable Human Machine Interface (HMI) designed to provide operators with intuitive monitoring and control of industrial automation systems. It features a touchscreen interface, Ethernet connectivity, and a compact design, making it suitable for machine operation, process visualization, and equipment diagnostics in manufacturing environments.
Technical Specifications
| Condition |
Obsolete / Surplus Available |
| Brand |
Omron |
| Part Number |
NS5-MQ11-V2 |
| Category |
HMI / MMI / OIT |
| Subcategory |
Operator Interface |
| Product Type |
Human Machine Interface (HMI) |
| Series |
NS |
| Display Size |
5.7 inches |
| Display Type |
Monochrome STN Touchscreen |
| Resolution |
320 × 240 Pixels |
| Supply Voltage |
24 VDC |
| Power Consumption |
15 W |
| Communication Interface |
10/100Base-T Ethernet |
| Memory Interface |
Memory Card Slot |
| Protection Rating |
IP65 / NEMA 4 (Front) |
| Case Color |
Ivory |
| Operating Temperature |
0°C to +50°C |
| Mounting Type |
Panel Mount |
| Dimensions |
195 × 142 × 54 mm |
| Weight |
2.14 lbs |
Information About NS5-MQ11-V2
The NS5-MQ11-V2 belongs to Omron's NS Series of programmable operator terminals, developed to simplify machine operation and improve production efficiency. It features a 5.7-inch monochrome STN touchscreen with a resolution of 320 × 240 pixels, providing clear visualization of machine status and process information. Built-in 10/100Base-T Ethernet enables communication with PLCs and industrial networks, while the memory card interface allows convenient project storage and maintenance. With an IP65/NEMA 4-rated front panel, the terminal is designed for reliable operation in industrial environments.
Key Features:
- NS Series Human Machine Interface (HMI)
- 5.7-inch monochrome STN touchscreen display
- 320 × 240 pixel screen resolution
- Built-in 10/100Base-T Ethernet communication
- Memory card interface for project storage and backup
- 24 VDC power supply
- IP65 / NEMA 4 front protection for industrial environments
- Compact panel-mounted operator interface
- Designed for machine monitoring and process control
- Compatible with multiple Omron automation systems
The NS5-MQ11-V2 provides reliable machine visualization and operator control for industrial automation applications.
