Description
The Omron GRT1-TS2P is a SmartSlice temperature input module designed for accurate temperature measurement using Pt100 resistance temperature detectors (RTDs). Featuring two high-resolution analog inputs, compact DIN rail mounting, and seamless integration with SmartSlice distributed I/O systems, it delivers precise temperature monitoring for industrial automation applications.
Technical Specifications
| Condition |
New |
| Brand |
Omron |
| Part Number |
GRT1-TS2P |
| Category |
PLCs / Machine Control |
| Subcategory |
PLC Module / Rack |
| Product Type |
Temperature Input Module |
| Series |
SmartSlice GRT1 |
| I/O System |
GRT1 I/O Bus |
| Analog Inputs |
2 |
| Temperature Sensor Type |
Pt100 RTD |
| Resolution |
13 Bit |
| Supply Voltage |
24 VDC |
| Connection Type |
Push-In |
| Mounting Type |
DIN Rail |
| Protection Rating |
IP20 |
| Operating Temperature |
-10°C to +55°C |
| Dimensions (H × W × D) |
84 × 15 × 74.4 mm |
| Compatible Controllers |
CJ, CS, NJ Series |
| Part Status |
Obsolete |
| Weight |
0.19 lbs |
Information About GRT1-TS2P
The GRT1-TS2P is part of Omron's SmartSlice GRT1 Series modular remote I/O platform. It provides two Pt100 temperature input channels with 13-bit resolution, allowing accurate temperature acquisition for process control and monitoring. The module connects to the GRT1 I/O Bus and is compatible with Omron CJ, CS, and NJ Series controllers. Its compact 15 mm-wide housing, push-in wiring technology, and DIN rail mounting simplify installation while minimizing panel space. Although discontinued, it remains widely used in existing SmartSlice systems.
Key Features:
- SmartSlice GRT1 Series temperature input module
- Two Pt100 analog temperature inputs
- 13-bit analog input resolution
- Compact 15 mm-wide design
- GRT1 I/O Bus communication
- Push-in wiring terminals
- DIN rail mounting
- IP20 protection rating
- Compatible with CJ, CS, and NJ Series controllers
- Designed for industrial temperature monitoring and process control
The GRT1-TS2P provides reliable and accurate temperature acquisition for distributed industrial automation systems.
