Description
The Omron E8F2B10C is a compact digital pressure sensor designed for precise pressure monitoring in industrial automation systems. It measures pressures from 0 to 1 MPa and provides both digital and analog outputs for control applications. This sensor is commonly used in systems requiring accurate and space-efficient pressure detection.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Industrial Automation |
| Part Number |
E8F2B10C |
| Subcategory |
Pressure Sensors |
| Product Type |
Digital Pressure Sensor |
| Series |
E8F2 Mini-Cube |
| Pressure Range |
0 to 1 MPa |
| Output Type |
Dual NPN, Analog (1–5 VDC) |
| Display Type |
LED with Bar Graph |
| Supply Voltage |
12–24 V DC |
| Connection Type |
Flying Leads |
| Mounting Connection |
R1/8" Taper Screw, M5 Female |
| Dimensions |
28 x 28 x 29 mm |
| Application |
Pressure Monitoring and Control |
| Weight |
0.24 lbs |
Information About E8F2B10C
The E8F2B10C is part of Omron’s E8F2 Mini-Cube series, developed for compact and high-performance pressure sensing in industrial environments. It operates on a 12–24 VDC supply and features dual NPN outputs along with a 1–5 V analog output for flexible integration. The unit includes an integrated LED display and bar graph for real-time pressure visualization. Its compact housing and pre-wired connection make it suitable for installation in confined spaces and machine assemblies.
Key Features:
- Pressure Range 0–1 MPa: Suitable for standard industrial pressure monitoring
- Dual NPN Outputs: Enables reliable digital switching for control systems
- Analog Output 1–5 VDC: Supports continuous pressure signal transmission
- Integrated LED Display: Provides clear pressure readings and status indication
- Compact Mini-Cube Design: Ideal for space-limited installations
- Teaching Function: Simplifies setup and threshold configuration
- Stable Measurement Logic: Reduces false outputs due to pressure fluctuations
- Pre-Wired Connection: Simplifies installation and wiring
The E8F2B10C delivers the reliability and precision required for pressure sensing and monitoring in industrial automation systems.
