Description
The Parker OEM300 is a compact power module designed to supply regulated DC power for Parker OEM Series servo drives and drive/controllers. The OEM300 operates from either 120VAC or 240VAC input and provides a fixed 75VDC output for powering servo motors and motion control equipment. It delivers 2.7A continuous current with 4.0A peak capability for industrial drive applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Parker |
| Category |
Automation Control Modules |
| Part Number |
OEM300 |
| Subcategory |
Servo Drive Power Modules |
| Module Type |
Regulated Power Supply Module |
| Input Voltage |
120VAC or 240VAC |
| Input Frequency |
50/60 Hz |
| Output Voltage |
75VDC Fixed |
| Continuous Output Current |
2.7A |
| Peak Output Current |
4.0A |
| Protection Features |
Over-temperature, Short Circuit, Over-voltage |
| Internal Function |
Power Dump Circuit Support |
| Mechanical Design |
Robust Metal Frame Construction |
| Manufacturer Status |
Discontinued by Manufacturer |
| Application Use |
Power Supply for OEM Series Drives and Controllers |
| Weight |
1.36 lbs |
Information About OEM300
The OEM300 is a Parker power supply module engineered specifically to support OEM Series motion control drives in automation and servo systems. It uses a robust metal frame design and provides a regulated 75VDC output suitable for powering connected drives and motors. The unit supports dual AC input voltage ranges at 50/60 Hz, making it compatible with standard industrial power distribution systems. It incorporates internal protection technologies including over-temperature monitoring, short-circuit protection, over-voltage circuitry, and an internal power dump function to safeguard both the module and the equipment it supplies.
Key Features:
-
Dual AC Input Voltage Range: Operates on 120VAC or 240VAC power at 50/60 Hz for flexible installation.
-
Fixed 75VDC Regulated Output: Provides stable DC supply voltage for OEM Series servo drive systems.
-
Continuous Current Capability: Delivers 2.7A continuous output for sustained drive and motor operation.
-
Peak Current Support: Provides up to 4.0A peak current for transient motion control demands.
-
Compact Power Module Format: Designed for space-efficient integration into OEM drive enclosures.
-
Integrated Protection Circuits: Includes over-temperature, short circuit, and over-voltage safeguards.
-
Internal Power Dump Function: Protects connected drive equipment during regenerative or fault conditions.
-
Rugged Metal Frame Construction: Built for industrial control environments requiring durable power hardware.
The OEM300 delivers the reliability and precision required for regulated DC power supply support in servo drive and motion control systems.
