Description
The Omron NJ501-1300 is a high-performance CPU unit designed for advanced motion control and machine automation applications. It combines large program capacity with multi-axis motion control and high-speed industrial networking to manage complex control systems. This controller is well suited for synchronized motion, robotics, and high-throughput manufacturing environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
PLCs/Machine Control |
| Part Number |
NJ501-1300 |
| Subcategory |
PLC Module/Rack |
| Series |
Sysmac NJ501 |
| Controller Type |
CPU Unit |
| Maximum I/O Capacity |
2560 points |
| Maximum Expansion Units |
40 units |
| Program Capacity |
20 MB |
| Motion Control Axes |
16 axes |
| EtherCAT |
Supported |
| EtherNet/IP |
Supported |
| USB Port |
Yes |
| Power Consumption |
1.90 A at 5 VDC |
| Mounting Method |
DIN rail |
| Weight |
1.5 lbs |
Information About NJ501-1300
The NJ501-1300 is part of Omron’s Sysmac NJ501 series, engineered to integrate logic control, motion control, and network communications within a single CPU platform. It features a robust industrial build designed for DIN rail mounting in control cabinets and demanding automation environments. The CPU supports EtherCAT for real-time motion control alongside EtherNet/IP for system-level communications. Its architecture allows seamless coordination of multiple servo axes and expansion units in complex machine configurations.
Key Features:
- High-Capacity CPU Engine: Supports large automation programs with fast execution performance.
- Integrated Motion Control: Controls up to 16 synchronized motion axes directly from the CPU.
- EtherCAT Networking: Provides deterministic, real-time communication for servo and I/O control.
- EtherNet/IP Connectivity: Enables plant-wide communication with HMIs, PLCs, and SCADA systems.
- Large Program Memory: Accommodates complex logic and motion applications without external expansion.
- Extensive Expansion Support: Handles up to 40 connected units and 2560 I/O points.
- DIN Rail Mounting: Simplifies installation in standard industrial control panels.
The NJ501-1300 delivers the reliability and precision required for high-speed motion control and advanced machine automation systems.
