The MVI69-MCM is a Modbus Master/Slave communication module from Allen-Bradley, designed for use with CompactLogix controllers. It enables seamless integration of Modbus RTU devices into Rockwell Automation systems by supporting both Modbus master and slave configurations.

Technical Specifications

Information About MVI69-MCM

The MVI69-MCM is a versatile Modbus Master/Slave communication module designed by ProSoft Technology for seamless integration with Allen-Bradley CompactLogix™ and MicroLogix™ 1500 controllers. It enables Rockwell PLCs to communicate with Modbus-compatible devices using Modbus RTU/ASCII protocols over serial connections. With dual configurable ports, broad protocol support, and robust diagnostics, the MVI69-MCM is ideal for connecting PLCs with third-party Modbus sensors, drives, meters, and remote systems in industrial automation networks.

Key Features:

• Compatibility: Allen-Bradley CompactLogix and MicroLogix 1500 platforms

• Protocol Support: Modbus RTU and ASCII (Master and Slave modes)

• Communication Ports: 2 x isolated serial ports (RS-232, RS-485, RS-422)

• Baud Rate Range: 110 to 115,200 bps

• Supported Devices: Up to 100 Modbus slaves (master mode), 30 Modbus masters (slave mode)

• Configuration Interface: Ladder logic-based with user-defined function blocks

• Diagnostics: LED indicators and onboard diagnostics for real-time monitoring

• Power Source: Backplane-powered via CompactLogix rack

• Form Factor: Compact 1769-style slot module for easy integration

• Application Scope: Industrial automation, legacy device integration, SCADA systems

This communication module is ideal for control engineers and system integrators who need a reliable, high-performance solution for bridging CompactLogix controllers with Modbus networks, especially in complex industrial environments such as oil & gas, water treatment, and manufacturing.
