Description
The ProSoft MVI46-DFCM is a DF1 Master/Slave communication module for Allen-Bradley SLC 500 processors, enabling efficient integration with DF1-compatible devices through ladder logic.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
ProSoft Technology
|
| Category |
|
| Part Number |
MVI46-DFCM
|
| Subcatecory |
|
| Product Type |
DF1 Master/Slave Network Interface Module |
| Rockwell Automation Compatible Series |
SLC 500 |
| Slot |
1 |
| Data Transfer Type |
Ladder Logic |
| Registers |
5000 max. |
| Read and Write Command Lengths |
125 Words max. |
| Commands per Master Port |
100 max. |
| Backplane Current Load |
800 mA 5V |
| Weight |
0.60 kgs |
Information About MVI46-DFCM
The MVI46-DFCM is a DF1 Master/Slave Network Interface Module developed for seamless communication between Allen-Bradley SLC 500 series controllers and external DF1-compatible devices. Installed in a single slot of the chassis, it supports full or half duplex DF1 protocols and enables robust data exchange via user-configured ladder logic. Equipped with one configuration port (RJ45) and two application ports (RS-232/422/485), this module allows multiple connections and commands while providing reliable control across industrial communication systems.
Key Features:
-
Multiple Port Interfaces: Includes 1 x RJ45 serial configuration port and 2 x RJ45 RS-232/422/485 application ports for versatile connectivity
-
High Command Capacity: Supports up to 100 commands per master port, with read/write lengths of up to 125 words each
-
Large Register Support: Manages up to 5000 registers for flexible data handling
-
Ladder Logic Integration: Communicates directly through ladder logic, streamlining the programming and data flow
-
Efficient Slot Design: Occupies a single I/O slot in the SLC 500 chassis, maintaining compactness and performance
The MVI46-DFCM provides an effective and scalable solution for adding DF1 protocol support to Allen-Bradley SLC 500 systems, enhancing communication between legacy and third-party devices.
