[properties]
| Properties |
RBwAPGR-5HacD2HnD |
| Description |
Small weatherproof Dual Band 2.4 / 5 GHz wireless access point with LTE antennas and miniPCI-e slot |
| Product Type |
Access Point |
[/properties] [specifications]
| Specifications |
Mikrotik wAP R ac Dual Band 2.4/5GHz Access Point wAP ac LTE Concurrent AP RBwAPGR-5HacD2HnD-US |
| Product code |
RBwAPGR-5HacD2HnD |
| Architecture |
ARM 32bit |
| CPU |
IPQ-4018 |
| CPU core count |
4 |
| CPU nominal frequency |
716 MHz |
| Switch chip model |
IPQ-4018 |
| RouterOS license |
4 |
| Operating System |
RouterOS |
| Size of RAM |
128 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-30°C to 60°C |
| IPsec hardware acceleration |
Yes |
| Suggested price |
$139.00 |
| Powering |
| Number of DC inputs |
2 (DC jack, PoE-IN) |
| DC jack input Voltage |
10-57 V |
| Max power consumption |
11 W |
| Max power consumption without attachments |
10 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
18-57 V |
| Wireless specifications |
| Wireless 2.4 GHz Max data rate |
300 Mbit/s |
| Wireless 2.4 GHz number of chains |
2 |
| Wireless 2.4 GHz standards |
802.11b/g/n |
| Antenna gain dBi for 2.4 GHz |
2.May |
| Wireless 2.4 GHz chip model |
IPQ-4018 |
| Wireless 2.4 GHz generation |
Wi-Fi 4 |
| Wireless 5 GHz Max data rate |
867 Mbit/s |
| Wireless 5 GHz number of chains |
2 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
2.May |
| Wireless 5 GHz chip model |
IPQ-4018 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
| Ethernet |
| 10/100/1000 Ethernet ports |
2 |
| Peripherals |
| Number of SIM slots |
1 Modem (Micro SIM) |
| MiniPCI-e slots |
1 |
| Other |
|
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
| Certification & Approvals |
| Certification |
CE, FCC, IC, EAC, ROHS |
| IP |
IP54 |
| Wireless specifications |
| 2.4 GHz |
|
| 1MBit/s |
Transmit (dBm): 22
Receive Sensitivity: (-100) |
| 11MBit/s |
Transmit (dBm): 22
Receive Sensitivity: (-94) |
| 6MBit/s |
Transmit (dBm): 23
Receive Sensitivity: (-95) |
| 54MBit/s |
Transmit (dBm): 19
Receive Sensitivity: (-78) |
| MCS0 |
Transmit (dBm): 23
Receive Sensitivity: (-95) |
| MCS7 |
Transmit (dBm): 18
Receive Sensitivity: (-73) |
| 5 GHz |
|
| 6MBit/s |
Transmit (dBm): 24
Receive Sensitivity: (-95) |
| 54MBit/s |
Transmit (dBm): 20
Receive Sensitivity: (-78) |
| MCS0 |
Transmit (dBm): 24
Receive Sensitivity: (-95) |
| MCS7 |
Transmit (dBm): 19
Receive Sensitivity: (-73) |
| MCS9 |
Transmit (dBm): 17
Receive Sensitivity: (-68) |
[/specifications] [accesories] [/accesories]
Mikrotik wAP R ac Dual Band Access Point RBwAPGR-5HacD2HnD-US
The Mikrotik wAP R ac is a versatile dual-band access point, supporting both 2.4GHz and 5GHz frequencies. Designed for concurrent LTE and Wi-Fi operations, it's perfect for diverse networking needs.
Quick Specs of RBwAPGR-5HacD2HnD-US:
- Dual Band: 2.4/5GHz
- LTE Concurrent AP
