[shortdesc]
- Powerful 1U rackmount router with 13x Gigabit Ethernet ports, 60GB M.2 drive for Dude database
[/shortdesc]
[properties]
| Properties |
RB1100AHX4 |
| Description |
The RB1100AHx4 Dude edition is faster than any previous RouterBOARD device (up to 2.2Gbps with AES128). It features several high speed storage connectors (two SATA and two M.2) for using a Dude database, proxy cache or any other storage intensive feature. It includes a 60GB M.2 drive already installed. |
| Product Family |
Mikrotik RB1100AHX4 Series |
| Product Type |
Ethernet Router |
| 10/100/1000 Ethernet ports |
13 |
| Serial console port |
RS232 |
| Number of USB ports |
1 |
| Memory Cards |
1 microSD |
| SATA ports |
2x SATA3 |
| Extended storage |
60GB M.2 SSD included |
| Extras |
Current Monitor
PCB temperature monitor
Voltage Monitor
Beeper |
| Dimensions |
443 x 148 x 44 mm |
| USB slot type |
USB type A |
| Number of AC inputs |
2 |
| Number of DC inputs |
2 (2-pin terminal, PoE-IN) |
| 2-pin terminal input Voltage |
-48, 20-57 V |
| Max power consumption |
33 W |
| Max power consumption without attachments |
25 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
20-57 V |
| Included |
SATA cables
Rack ears
M.2 SSD 60GB
Screw and feet kit (K10)
2x IEC cords |
[/properties][specifications]
| Specifications |
RB1100DX4 |
| Memory |
1 GB |
| NAND Storage size |
128 MB |
| CPU |
AL21400 1.4 GHz |
| CPU core count |
4 |
| Switch chip model |
RTL8367 |
| OS |
RouterOS level 6 license |
| MTBF |
Approximately 200.000 hours at 25C |
| Temperature |
-40°C to 70°C tested |
| IPsec hardware acceleration |
Yes |
| Certification |
CE, EAC, ROHS |
| IP |
IP20 |
[/specifications]
MikroTik RB1100DX4 Router
The RB1100DX4 offers a powerful and efficient routing solution suitable for both individuals and organizations in need of high-performance networking capabilities. These routers are specifically engineered to effortlessly manage demanding networking tasks, delivering users the necessary flexibility and power to accommodate intricate networks and high-speed connectivity. One of the RB1100DX4 Router's notable features is its support for high-speed storage interfaces, including two SATA and two M.2 slots.
Quick Specs:
-
13x 10/100/1000 Ethernet Ports
-
1GB RAM
-
AL21400, 4 cores, 1.4 GHz CPU
-
2x M.2 Slots
Please see the related tabs for the RB1100DX4 datasheet and compatible accessories.
