Overview

Kioxia KCD8DRUG7T68 CD8-R Series 7,680 GB PCIe 4.0, NVMe 1.4 Solid State Drive

Specifications

Model Number: KCD8DRUG7T68

Brand:   Kioxia

Alt Part Number(s):    KCD8DRUG7T68

Product Type: Solid State Drive

Technical Description

Brand:  Kioxia

Model:  KCD8DRUG7T68

Capacity: 7,680 GB (7.68TB)

Form Factor: 2.5-inch, 15mm height (U.2)

Interface: PCIe 4.0 x4, NVMe 1.4

Max Interface Speed: 64 GT/s

Flash Type: BiCS FLASH TLC (Triple-Level Cell)

Sequential Read (128 KiB): 7,100 MB/s

Sequential Write (128 KiB): 6,000 MB/s

Random Read (4 KiB): 1,150,000 IOPS

Random Write (4 KiB): 200,000 IOPS

Input Voltage: 12V ±10%, 3.3V ±15%

Active Power Consumption: 19W (typical)

Idle Power Consumption: 5W (typical)

MTTF: 2.5 million hours

DWPD: 1 (Drive Writes Per Day)

Operating Temp: 0°C to 75°C

Non-Operating Temp: -40°C to 85°C

Humidity: 5% to 95% RH (operating)

Vibration (Operating): 21.27 m/s² (2.17 Grms, 5–800 Hz)

Shock (Operating): 9,800 m/s² (1,000 G, 0.5 ms)

*
