[shortdesc]
- SFP+ transceiver module
- 10 GigE
- 10GBase-SR
- LC multi-mode
- up to 984 ft
- 850 nm
[/shortdesc]
[properties]
| Properties |
Cisco EX-SFP-10GE-SR 10GBASE-SR SFP+ Transceiver Module |
| Description |
10GBASE-SR SFP+ transceiver for short-range data transmission over multimode fiber |
| Product Type |
SFP+ Optical Transceiver |
| Compatibility |
Cisco switches and routers with SFP+ ports |
| Mount Type |
Hot-swappable into SFP+ slots |
[/properties] [specifications]
| Interface |
Dual LC/PC connector |
| Wavelength |
850 nm |
| Data Rate |
10 Gbps |
| Max Distance |
300 m (OM3), 400 m (OM4) |
| Fiber Type |
Multimode Fiber (MMF) |
| Transmit Power |
-1.2 to -7.3 dBm |
| Receive Power |
-1.0 to -9.9 dBm |
| Power Consumption |
1.0 W |
| Operating Temperature |
0°C to 70°C (Commercial) |
| Dimensions |
56.5 mm x 13.4 mm x 8.5 mm |
| Weight |
< 75 g |
[/specifications] [accesories]
| Included Items |
EX-SFP-10GE-SR module with dust cap (included in the box) |
| Compatible Devices |
Cisco devices with SFP+ ports supporting 10GBASE-SR |
[/accesories]
Juniper EX-SFP-10GE-SR Transceiver
This Juniper Networks EX-SFP-10GE-SR SFP+ transceiver provides 10GBase-SR throughput up to 300m over multi-mode fiber (MMF) at a wavelength of 850nm using a LC connector.
