Description
The Hayward HLX-LOC-DSP is a genuine OEM replacement local touchscreen display designed for Hayward OmniLogic pool and spa automation systems. The Hayward HLX-LOC-DSP restores full local system control, allowing users to configure equipment, monitor operating status, and manage automation functions through a responsive full-color touchscreen interface.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Hayward |
| Category |
HVAC Control |
| Part Number |
HLX-LOC-DSP |
| Subcategory |
Display Module |
| Product Type |
Local Touchscreen Display |
| Compatibility |
Hayward OmniLogic Automation Systems |
| Compatible Models |
HLBASE, HLBASE-X288 |
| Display Type |
Full-Color Touchscreen |
| Connection Type |
Ribbon Cable to Main Control Board |
| Installation |
Surface-Mounted Local Access Panel |
| Included Components |
Display Module, Ribbon Cable, Liquid Crystal Display Board |
| Application |
Pool and Spa Automation |
| Primary Functions |
Equipment Control, Scheduling, Diagnostics, System Configuration |
| Construction |
Weather-Resistant for Outdoor Equipment Pads |
| Replacement Type |
Genuine Original Equipment Manufacturer Replacement |
| Shipping Dimensions |
10.9 × 6.7 × 4.2 in. |
| Weight |
3.0 lb (1.36 kg) |
Information About HLX-LOC-DSP
The HLX-LOC-DSP is a replacement local display module developed for the Hayward OmniLogic automation platform and compatible HLBASE and HLBASE-X288 control systems. It connects directly to the OmniLogic main control board through a ribbon cable, providing reliable local access to pumps, heaters, lighting, sanitization equipment, schedules, and system diagnostics. The display is designed as a direct OEM replacement for damaged, unresponsive, or malfunctioning touchscreen interfaces without requiring changes to the automation controller. Its weather-resistant construction makes it suitable for equipment pad installations while maintaining seamless integration with the OmniLogic automation ecosystem.
Key Features:
- Genuine Original Equipment Manufacturer Replacement: Manufactured by Hayward for direct compatibility with OmniLogic automation systems.
- Full-Color Touchscreen Display: Provides intuitive navigation for programming, scheduling, and equipment control.
- Direct Replacement Design: Installs using the existing ribbon cable connection without system reconfiguration.
- OmniLogic Compatibility: Designed for HLBASE, HLBASE-X288, and compatible OmniLogic control panels.
- Complete Display Assembly: Includes the local display module, ribbon cable, and liquid crystal display board.
- Weather-Resistant Construction: Engineered for dependable operation in outdoor pool equipment environments.
- Local Equipment Management: Controls pumps, heaters, lighting, valves, sanitization systems, and automation schedules.
- Diagnostic Access: Provides convenient access to system status, configuration menus, and operational information.
The HLX-LOC-DSP delivers the reliability and precision required for dependable local control of Hayward OmniLogic pool and spa automation systems.
