| Video |
|---|
| Imaging Device |
1/2.8" CMOS |
| Resolution |
3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720,
1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) (@6MP Max. 5fps) |
| Min. Illumination |
Color: 0.1Lux(F1.6, 1/30sec)
BW: 0.01Lux(F1.6, 1/30sec) |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
5~125mm(25x) zoom (digital 32x, total 800x zoom) |
| Max. Aperture Ratio |
F1.6(Wide)~F3.73(Tele) |
| Angular Field of View |
H: 57.42°(Wide)~2.71°(Tele) / V: 33.54°(Wide)~1.55°(Tele) |
| Min. Object Distance |
5m(16.4ft) |
| Focus Control |
Oneshot AF, Focus save |
| Lens Type |
DC auto iris |
| Pan / Tilt / Rotate |
|---|
| Pan Range |
360° Endless |
| Pan Speed |
Max. 700°/sec, Manual: 0.024°/sec~250°/sec |
| Tilt Range |
110°(-20°~90°) |
| Tilt Speed |
Max. 500°/sec, Manual: 0.024°/sec~250°/sec |
| Sequence |
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule |
| Preset Accuracy |
Up to ±0.1°, Pan/Tilt correction |
| Operational |
|---|
| Camera Title |
Displayed up to 85 characters |
| Direction Indicator |
Support |
| Day & Night |
Auto(ICR)/Color/BW/Schedule |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
Extreme WDR(120dB) |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Defog |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, Quadrangle Support
- Color: Grey/Green/Red/Blue/Black/White
- Mosaic |
| Gain Control |
Manual / Max |
| White Balance |
ATW /Narrow ATW /AWC /Manual /Indoor /Outdoor /Mercury /Sodium |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
Classified object type : Person/Face/Vehicle/License plate
Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analytics events based on AI engine
- Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Motion detection, Tampering, Fog detection, Shock detection, Virtual area(Appear/Disappear)
* Audio detection, Sound classification(with NW I/O Box) |
| Alarm Triggers |
Analytics, Network disconnect
* Alarm input(with NW I/O Box) |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
PTZ Preset
Handover
* Alarm output(with NW I/O Box) |
| Water Removal |
Support(Spinning dry) |
| Auto Tracking |
Object auto tracking(Person/Vehicle), Target lock tracking |
| Network |
|---|
| Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast (128 user)
Multiple streaming(Up to 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP, NTCIP, MQTT |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Security |
|---|
| OS / Firmware Protect |
Secure boot, Signed firmware, Firmware encryption |
| User authentication |
Digest Authentication, Prevent brute-force attack |
| Network authentication |
802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) |
| Secure Communication |
HTTPS, SRTP, WSS(Web socket secure) |
| Access Control |
IP address filtering |
| Data Protect |
Authentication information encryption, ZIP compression encryption |
| Audit |
User Access/System/Event log |
| Device ID |
Device Certificate(Hanwha Techwin Root CA, pre-installed) |
| Secure Storage |
TPM 2.0 with FIPS 140-2 level2 |
| Security Certificate |
Secure by default |
| General |
|---|
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian,
Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot 1TB |
| Memory |
4GB RAM, 512MB Flash |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F ~ +131°F) /
+74°C(+165°F) (MAX) based on NEMA-TS 2(2.2.7)
* Start up should be done at above -30°C
0~95% RH(Non-condensing) |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / 0~90% RH |
| Certification |
IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9) |
| Input Voltage |
PoE+(IEEE802.3at, Class4) |
| Power Consumption |
Typical 24W, Max 25.5W |
| Mechanical |
|---|
| Color / Material |
Body : White / Aluminum
Head : Black / Polycarbontate
Hard-coated dome |
| RAL Code |
White: RAL9003 / Black: RAL9005 |
| Product Dimensions / Weight |
ø158x293.3mm(6.22x11.55") / 3.2Kg(7.05lb) |
| DORI (EN62676-4 standard) |
|---|
| Detect (25PPM/ 8PPF) |
Wide: 121.5m(398.7ft) / Tele: 2813.9m(9232.1ft) |
| Observe (63PPM/ 19PPF) |
Wide: 48.6m(159.5ft)/ Tele: 1125.6m(3692.8ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 24.3m(79.7ft)/ Tele: 562.8m(1846.4ft) |
| Identify (250PPM/ 76PPF) |
Wide: 12.2m(39.9ft) / Tele: 281.4m(923.2ft) |
